1400C Low Vacuum Degree Furnace Heat Chamber 380V 50HZ Customized
Product Detail
Specification Furnace Heat Chamber
| Heating chamber for vacuum annealing furnace components | ||||
| Valid zone | Maximum temperature (℃) | Heating power (kw) | Ultimate vacuum (Pa) | Gas cooling pressure (bar) |
| 450x300x300 | 1320 | 40 | 5x10-3or4x10-1 | 2 |
| 600x400x400 | 1320 | 80 | 5x10-3or4x10-1 | 2 |
| 750x500x500 | 1320 | 120 | 5x10-3or4x10-1 | 2 |
| 900x600x600 | 1320 | 150 | 5x10-3or4x10-1 | 2 |
| 1200X600X600 | 1320 | 200 | 5x10-3or4x10-1 | 2 |
| 1500x800x800 | 1320 | 360 | 5x10-3or4x10-1 | 2 |
|
The heating chamber can adopt graphite tube heating and multi-layer graphite felt or graphite hard felt insulation structure; For products with high requirements or special materials brazing, the heating chamber can also adopt molybdenum belt heating and molybdenum sheet and stainless steel sheet composite insulation structure; The size of valid zone can be customized according to customer requirements; Computer control system; |
||||
| Product description: Mainly used for bright annealing of high alloy steel, magnetic materials, stainless steel, titanium alloy, nonferrous metals and other materials. | ||||
features
1. Temperature control accuracy: ±1°C, furnace temperature uniformity: ±2°C (depending on the size of the heating chamber).
2. Microcomputer control, multi-channel control, realizes multi-channel simultaneous heating, heat preservation and cooling, easy to operate. Programmable, PID self-tuning, automatic heating, automatic heating, automatic cooling, no need to be on duty; can be equipped with computer communication through the computer to operate the electric furnace (starting the electric furnace, stopping the electric furnace, pausing the heating, setting the heating curve, heating curve storage, history curve Wait)
3. Fast heating (the heating rate can be adjusted from 1°C/min to 20°C/min).
4. Imported refractory material, good thermal insulation performance, high temperature resistance, resistance to rapid cooling and rapid heating.
5. Electric or manual hydraulic lifting of furnace door.
Furnace can be customized according to customer needs
