Mill Finish 1060 H14 Aluminium Coil Roll 1mm 2mm ASTM B209 EN573-1
1060 H14 1mm 2mm Thick Mill Finish Aluminium Coil Roll Price Per Ton
Properties of 1060 Aluminum Coil:
1060 aluminum coil is pretty similar to 1050 aluminum alloy with more than 0.1% of aluminum by weight. 1060 aluminum coil contains 0.05% cooper, thus, its conductivity is 55%. Besides, 1060 aluminum coil is relatively low strength, essentially pure aluminum alloy with many different tempers, such as O (annealed), H12, H14, H16, H18, etc. What’s more, other aluminum coil belonging to commercial pure wrought family are available, including 1050, 1070, 1100 and so on.
Chemical Composition of 1060 Aluminum Coil (%):
| Elements | Si | Cu | Mn | Zn | Mg | Ti | V | Fe | Al |
| Contents | 0.25 | 0.05 | 0.03 | 0.05 | 0.03 | 0.03 | 0.05 | 0.35 | 99.6 |
Mechanical Properties of 1060 Aluminum Coil:
| Temper | Specifications | Tensile Strength | Yield Strength | Elongation | |
| Thickness(in.) | (ksi) | (ksi) | (%) | ||
| 1060-O (annealed) |
0.006-0.019 | 8.0-14.0 | 2.5 | Min 15 | |
| 0.020-0.050 | Min 22 | ||||
| 0.051-3.000 | Min 25 | ||||
| 1060-H12 1060-H22 |
0.017-0.050 | 11.0-16.0 | 9.0 | Min 6 | |
| 0.051-2.000 | Min 12 | ||||
| 1060-H14 1060-H24 |
0.006-0.019 | 12.0-17.0 | 10.0 | Min 1 | |
| 0.020-0.050 | Min 5 | ||||
| 0.051-1.000 | Min 10 | ||||
| 1060-H16 1060-H26 |
0.006-0.019 | 14.0-19.0 | 11.0 | Min 1 | |
| 0.020-0.050 | Min 4 | ||||
| 0.051-0.162 | Min 5 | ||||
| 1060-H18 1060-H28 |
0.006-0.019 | Min 16.0 | Min12.0 | Min 1 | |
| 0.020-0.050 | Min 3 | ||||
| 0.051-0.128 | Min 4 | ||||
1060-H112 |
0.250-0.499 | Min 11.0 | Min 7.0 | Min 10 | |
| 0.500-1.000 | Min 10.0 | Min 5.0 | Min 20 | ||
| 1.001-3.000 | Min 9.0 | Min 4.0 | Min 25 | ||
Applications of 1060 Aluminum Coil:
1060 aluminum coil has good corrosion resistance as well as poor machine-ability, and its machine-ability can be improved in harder (cold working) tempers, such as H16 and H18. For its features above, 1060 aluminum coil has a vast application, such as electric and chemical equipment, railroad tank cars, gutter, ACP ( aluminum composite panel ), sheathed coil material for insulation, thermal insulation, led housing, industrial use, etc.
Information of 1060 Aluminum Coil:
1-A: What is a 1060 aluminum coil?
1060 aluminum coil belongs to 1000 series aluminum coil, 1060 aluminum alloy is aluminum content (mass fraction) of 99.60%, not heat treatment to strengthen. Pure aluminum surface is silvery-white, its density decreases with increasing purity or temperature. 1060 aluminum production process is a relatively simple, relatively mature technology, the price relative to other high-grade aluminum alloys is much cheaper.
1-B: What are the characteristics of 1060?
1060 aluminum coil has high plasticity, corrosion resistance, electrical conductivity, and thermal conductivity, but the strength is low, heat treatment can not be enhanced machinability is not good; gas welding, hydrogen atomic welding, and contact welding are not easy to braze; Processing and extension, bending.
1-C: 1060 aluminum coil equivalent name:
A1060 aluminum coil, 1060a aluminum coil, aa1060 aluminum coil, 1060aa aluminum coil,
Al1060 aluminum coil, a 1060 aluminum coil, aa 1060 aluminum coil, en1060 grade aluminum coil, etc
