6063 T5 T6 Anodized Aluminum Alloy Tube ASTM B210 ASTM B241
6063 T5 T6 Small Diameter Capillary Anodizing Surface Aluminium Alloy Pipe
6063 Aluminum Pipe Parameters:
| Product | 6063 Aluminum Pipe |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, GB/GB/T6893-2000, GB/T4437-2000, ASTM B210, ASTM B241, ASTM B234, JIS H4080-2006, etc |
| Grade | 6000 Series |
| Material | 6061, 6062, 6063, 6082, etc |
| Surface treatment | Oxidation, electrophoretic coating, fluorine carbon spraying, powder coating, wood grain transfer printing, mechanical drawing, mechanical polishing, sand blasting |
| Temper | T3 - T8 |
| Shape | Round/Square/Oval |
| Application | Aluminum tube is widely used in all walks of life, such as: automobile, ship, aerospace, aviation, electronics, agricultural and mechanical and electrical, home, etc |
| Outer diameter | 3-250mm or as required |
| Wall thickness | 0.5-50mm or as required |
| Length | 10-6000mm or as required |
| Inspection | Fully accept all the third party to test before shipment. |
| Packing |
Standard export seaworthy package. Wooden package. Suit for all kinds of transport, or as required. |
| Delivery time | 7-10 working days after receiving the deposit or both parties negotiate according to the order quantity |
| Payment terms | 30%T/T Advance + 70% Balance |
| MOQ | 2 tons |
6063 Aluminum Pipe Chemical Composition:
| Alloy | Si | Fe | Cu | Mg | Zn | Mn | Ti | Cr | Al |
| 6063 | 0.2-0.6 | ≤0.35 | ≤0.1 | 0.45-0.9 | ≤0.1 | ≤0.1 | ≤0.1 | ≤0.1 | remainder |
6063 Aluminum Pipe Mechanical Properties:
| Alloy | Wall Thickness/mm | Tensile Strength (Rm/Mpa) | Yield Strength (Rp0.2/Mpa) | Elongation ( %) | |
| A50mm | A5.65 | ||||
| 6063-T4 | ≤12.5 | 130 | 70 | 14 | 12 |
| >12.5-25 | 125 | 60 | — | 12 | |
| 6063-T6 | All | 205 | 170 | 10 | 9 |
6063 Aluminum Tube Applications:
It is widely used in building profiles, irrigation pipes, pipes, rods and profiles for vehicles, platforms, furniture, lifts and fences.
6063 Aluminum Pipe Informations:
1-A: What is 6063 aluminum tube?
6063 is a low alloyed al-mg-si alloy with high plasticity.It has excellent processing performance, excellent weldability, extrusion and electroplating, good corrosion resistance, toughness, easy to polish and color film, good anodizing effect, it is a typical extrusion alloy.6063 aluminum alloy profile with its good plasticity, moderate heat treatment intensity, good welding performance and anodized treatment, surface gorgeous color and many other advantages and is widely used in building profile, irrigation pipe, for vehicles, platform, furniture, lift, fence used in the pipe, bar, profile.
1-B: Are aluminum pipes made through the process of extrusion?
Yes, aluminum pipes are an extruded product. Of the 6000 aluminum series, 6063 aluminum is considered excellent for extruded aluminum. Pipes are a hollow extruded aluminum and are not intended for weight bearing or high wear applications. Rather, this grade is best in supportive structural applications where strength is not critical.
1-C: What is the main alloying element for this aluminum grade?
It is primarily alloyed with magnesium and silicon.
