444 SS Sheet Metal Cold Rolled 1mm Stainless Steel Sheet
SS Sheet Metal 444 Cold Rolled 1mm 1.5mm 2.0mm Stainless Steel Sheet
444 Stainless Steel Sheet Description:
The yield strength of stainless steel SUS444 is 1.5 times that of carbon steel and 6 times that of FRP. It has outstanding performance for shock resistance, snow resistance, wind pressure resistance and stamping resistance.
SUS444 ferritic stainless steel has high thermal conductivity. 130%-150% of chrome-nickel austenitic stainless steel is very suitable for heat exchange applications. The coefficient of thermal expansion is small, and the squad is only 60%-70% of chrome-nickel austenitic stainless steel. It is very suitable for use under conditions of thermal expansion and contraction and thermal cycling without deformation.
The steel has good plasticity and toughness and is suitable for stretching, forming and stamping. The steel grade is the most excellent in corrosion resistance. The corrosion resistance in high chloride media is superior to that of ordinary ferritic stainless steel and austenitic stainless steel, and it does not cause stress corrosion cracking of chloride. The steel can be welded by ordinary stainless steel, especially for food processing equipment, heat exchangers, hot water tanks, water storage tanks, solar collector panels, etc.
Compared with other stainless steels, the steel is the only one that has magnetic properties. In view of this, the steel is not suitable for use in sensitive electronic equipment, electromagnetic equipment that is subject to electromagnetic waves and magnetic interference.
444 Stainless Steel Sheet Chemical Analysis:
SUS444 (00Cr18Mo2) is an ultra-low carbon nitrogen, 18% chromium and 2% molybdenum, high corrosion resistant ferritic stainless steel.
The steel grade is generally stabilized with tantalum or titanium to avoid intergranular corrosion after welding. This steel grade is particularly suitable for use in a variety of water treatment plants.
C:≤0.025
Mn:≤1.00
Si:≤1.00
Cr:17.5~19.5
Ni:≤1.00
P:≤0.04
S:≤0.03
Mo:1.75~2.5
N:≤0.035
Ti+Nb:≥0.2+4(%C+%N)
444 Stainless Steel Sheet Physical Properties:
| Electrical Resistivity: microhm-in (microhm-cm) | 68 ° F (20 ° C): 22.50 (57) |
| Specific Heat: BTU/lbl° F (kJ/kg•K) | 32 - 212 ° F (0 - 100 ° C): 0.102 (0.427) |
| Thermal Conductivity: BTU/hr/ft2/ft/° F (W/m•K) | At 212 °F (100 °C): 15.5 (26.8) |
| Mean Coefficient of Thermal Expansion: in/inl° F (µm/m•K) | 32 - 212 ° F (0 - 100 °C): 6.1 x 10-s (11.0) |
| Modulus of Elasticity: ksi (MPa) | 29 x 103 (200 x 103) in tension |
| Melting Range | 2700 - 2790 ° F (1482 - 1532 °C) |
SUS304 stainless steel VS SUS444 stainless steel
SUS304——0Cr18Ni9 SUS444——00Cr18Mo2
SUS304——Non-magnetic SUS444——Magnetic
SUS304——Low carbon SUS444——Super Low Carbon
SUS304——Good rust and corrosion resistance
SUS444——Better rust and corrosion resistance
SUS304——Brighter surface SUS444——Surface gloss
SUS304——Harmless to the human body, food grade
SUS444——Harmless to the human body, food grade
