Polish 2205 Stainless Steel Bars Solid Round Bar H13K9 K10 K11
2205 Stainless Steel Bars 2205 Stainless Steel Solid Round Bar
2205 Stainless Steel Bar Specifications:
| Grade | Duplex 2205 – UNS S32205 |
| Length | 1 to 6 meter or as per customer's requests. |
| Round bar size | Diameter: 6mm - 630mm Dia |
| Flat bar size | Thickness: 2mm - 100mm |
| Width: 10mm - 500mm | |
| Square bar size | 4mm*4mm - 100mm*100mm |
| Tolerance | H13K9, K10, K11, K12, H12, H10, H8, H11, H9 or as per clients’ requirements |
| Condition | Cold Drawnd, Ground & Polished, Annealed round bar, Sheared & Edged, Rolled Flat |
| Form | Half Round,Round, Hex (A/F), Triangle, Rectangle, Rod, Precision Ground Bar, Square, Profiles, Forging, Round Rod |
| Manufacturing process |
Surface finish 0.5 µmm to 1.5µmm max Peeled Bars: Dia. Ø15 mm -120 mm. Peeled, Straightened, Centreless Ground & Polished. Straightness upto 0.5mm/mtr to 1mm /mtr. 240,400,600 Grit Belt Cold Drawn Bright Bar: Dia. 2.5 mm to 14 mm. Annealed, Pickled, Cold Drawn, Centreless Ground & Polished. |
| Inspection |
Bundles are made of 500/1000kgs each packed.
We issue EN10204/3.1 Certificate
Free from any internal defects
All required Mechanical and metallurgical tests are carried out at our works.
Each lot is tested and ensured that material is free from Radio active contamination.
Each Bar is tested for size tolerance,Ovality,length and Roughness.
Container is fumigated before stuffing. All wooden box /blockes are also fumigated.
|
2205 Stainless Steel Bar Mechanical Properties:
| S31803 / S32205 | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 1350 °C (2460 °F) |
Psi – 80000 MPa – 550 |
Psi – 116000 MPa – 800 |
15 % |
2205 Stainless Steel Bar Advantages:
1. Good general corrosion resistance
2. High resistance to chloride stress corrosion cracking
3. High Strength
4. Very Good weldability and workability
5. Good sulfide stress corrosion resistance
6. Resistance to chloride pitting and crevice corrosion
2205 Stainless Steel Bar Surface Finish:
| CD | Cold drawn | P | Polished |
| BD | Bright drawn | SRE | Slit rolled edge |
| CG | Centreless ground | HF | Hot finished |
| CF | Cold finished | HRAP | Hot rolled annealed and pickled |
| P&T | Peeled and turned | RT | Rough turned/peeled |
| ST | Smooth turned | PR | Peeled and reeled |
2205 Stainless Steel Bar Packing:
1. Stainless steel bar covered with woven bag for protection in transportation.
2. All stainless steel bar will be loaded in strong wooden packages.
3. Every packages loaded with good shoring and strengthening.
4. Take container loading pictures and seal the container.
5. Transportation speed is quick, and keep customer each step informed.
