36V 17.5Ah E Bike Lithium Ion Battery Pack With Samsung 18650 35ET Cell

Price Negotiable
Price: Negotiation
MOQ: Negotiation
Delivery Time: Negotiable
Brand: Vodno
Product Description

36v 17.5Ah E-bike Lithium Ion Battery Using Samsung 18650 35ET Cell

18650 Li-ion batteries are the battery of choice when designing for higher voltage and current requirements. Li-ion have relatively low self-discharge rates, and are capable of high discharge currents and better performance than nickel and lead based batteries.



Overview

Quality + Safety = VODNO e-bike battery

E-bike lithium battery packs are available in several chemistries, You could make a decision according to your market.

Lithium cobalt oxide provides the greatest energy density

Lithium manganese offers greater safety with lower energy density than lithium cobalt oxide

Lithium iron phosphate provides high discharge rate capabilities, as well as long cycle and calendar life



Why choose us :

1, Strong design and provide solution based on difference shape, capacity and voltage to match your application.
2, high quality OEM logo or sticker.
3, Easy and cheap apply difference certification based on your market.
4, Rich experience to select suitable battery charger.
5, Professionally arrange to ship battery by sea or by air door to door.
6, Best price provide original China’s brand cell including BK,BYD,Lishen,Tession,etc and Samsung, lg, Panasonic,Sony cell etc.

Battery pack configuration:

Rhino Voltage Configuration Battery capacity
  36v 10S 17.5Ah-24.5Ah
  48v 13S 14Ah-17.5Ah



Specifications

Model VDO-Li3617.5 ( Samsung 35ET 3500mah)
General Characteristics
Nominal voltage 36V (10S5P)
Nominal capacity@0.2C 17.5Ah
Nominal energy 630Wh
Internal Resistance 200≦mΩ
Life cycle >600 Cycles @0.2C Charging /Discharging at 90%DOD until 70% Capacity
Standard Charging
Charging voltage 42.0+/-0.2V
Charging Mode(CC/CV) At 0℃~45℃temperature, charged to 42V at constant current 0.5C3A,and then at constant voltage 42V until the current drops to 0.5C3A
Charging Current 3A
Max.Charging Current 5A
Standard Discharging
Discharging Current 10A
Max.Continuous Current 15A
Max.Pulse Current 30A(<3S)
Discharging cut-off Voltage 28V
Operating conditions
Operating temperature Charge 0℃~60℃
Discharge -20℃~60℃
Storage temperature -10℃~45℃
Water dust resistance N/A
Structure
Casing Customer provided
Approx.Weight ≤3.78kgs
BMS function
CAN communication Yes/No



Application
