Rechargeable Lifepo4 Battery Pack 576Wh 24v 24ah Lithium Ion Battery

Price Negotiable
Price: Negotiation
MOQ: Negotiation
Delivery Time: Negotiable
Brand: Vodno
Product Description

Support Battery In Series And Parallel Rechargeable Lithium Lifepo4 Battery Pack 24v 24ah With Long Life Span

LIFEPO4 is the more efficient technology batteries , knocking out traditional lead acidbatteries . VODNO provides a complete line of 12 ,24 and 48 volt batteries for use inRVS , Boats , Evs and off-grid applications and much more.



Overview

VODNO innovative technology built to your product standards . We approach every OEMpartnership with openness. so we can understand your needs and you can understand ourcompetencies , standards and commitment to delivery .from engineering and design to development teams that prioritize performance andcustomer experience , trust VODNO to be your single source partner to deliver the custom battery solution that achieves your vision . When you re looking for a trust worthy partner to build your custom product , let our experts reduce development risk and bring a high-quality product to market faster for you.

Specifications

Model 24V 24Ah 576Wh
Nominal voltage 25.6V
Nominal capacity@0.2C 24Ah
Dimensions(W*D*H) 229*138*212*217
Battery connection 8S4P
Recommended charging voltage 29.2V
Max. charging current 24A
Max.continuous discharge current 24A
Max.peak discharge current 60A ( <5S)
Discharging cut-off voltage 20V
Operating temperature Charge 0℃~45℃
Discharge -10℃~60℃
Storage temperature -10℃~60℃
Storage duration 12Months @20℃~25℃
Water dust resistance IP65-IP67
Weight 6.5KGS
Lifecycle times >2000 Cycles ( 0.2C 80% DOD)

Warranty

VODNO promise customer 3 years warranty based on battery performance,any unqualified battery are credit replacement within 3 years, no extra maintenance fees. but VODNO has no obligation under this Limited Warranty for Product subjected to the following conditions (including but not limited to):

  • Damage caused during shipping or mishandling of the Product

  • Damage due to improper installation; loose terminal connections, under-sized cabling, incorrect series (cannot be used in series) or parallel connections, reverse polarity connections or insufficient space for airflow

  • Environmental damage such as inappropriate storage conditions as defined by the VODNO, exposure to extreme hot or cold temperatures, fire or freezing, or water damage, impact or collision

  • Damage due to improper operation or maintenance such as under- or over- charging the Product, cold temperature charging, lack of cleaning resulting in corroded terminal connections or build-up of dirt, debris, organic matter, fossil fuels or chemicals on the Product casing

  • Improper use of CAN cables such as improper connections or not connecting them

  • Installing CAN communication devices that do not follow the appropriate CANbus guidelines as defined by the VODNO

  • Product that has been opened, modified or tampered with

  • Tampering or removal of manufacture date codes

  • Product that was used for applications other than which it was designed and intended for by the VODNO

  • Product that was under-sized for the application

This Limited Warranty does not cover a Product that has reached its normal end of life due to usage which may occur prior to the Warranty Period. A battery can deliver only a fixed amount of Energy over its life which will occur over different periods of time depending on the application. The Manufacturer reserves the right to deny a warranty claim if the Product is determined, upon inspection, to be at its normal end of life even if within the Warranty Period.
