Customizable Diesel Forklift Truck 2.5 Ton Hydraulic Four Wheel
Price:
Negotiable
MOQ:
1 unit
Delivery Time:
45 working days
Brand:
Huahe
Product Description
Customizable Diesel Forklift Truck 2.5 Ton Hydraulic Four Wheel
【Customizable/Factory outlet】2.5Ton Diesel Forklift Truck
Detail
| 1 | Model | UNIT | HH20 (Z) | HH20 (Z) | HH25 (Z) | HH25 (Z) | ||
| 2 | Power type | Diesel | ||||||
| 3 | Rated capacity | kg | 2000 | 2000 | 2500 | 2500 | ||
| 4 | Load center | mm | 500 | 500 | 500 | 500 | ||
| 5 | Lift height | mm | 3000 | 3000 | 3000 | 3000 | ||
| 6 | Free lift height | mm | 110 | 110 | 110 | 110 | ||
| 7 | Fork size(L*W*T) | mm | 1070×120×40 | 1070×120×40 | 1070×120×40 | 1070×120×40 | ||
| 8 | Fork outside spread(Min./Max.) | mm | 245/1030 | 245/1030 | 245/1030 | 245/1030 | ||
| 9 | Mast tilt range(F/R) | deg | 6/12 | 6/12 | 6/12 | 6/12 | ||
| 10 | Front overhang | mm | 480 | 480 | 480 | 480 | ||
| 11 | Overall dimensions | Length to face of fork | Without of fork | mm | 2500 | 2500 | 2570 | 2570 |
| 12 | With fork | mm | 2540 | 2540 | 2610 | 2610 | ||
| 13 | Wheel width | mm | 1160 | 1160 | 1160 | 1160 | ||
| 14 | Mast lowered height | mm | 2050 | 2050 | 2050 | 2050 | ||
| 15 | Mast extended height | mm | 4000 | 4000 | 4000 | 4000 | ||
| 16 | Overhead guard height | mm | 2150 | 2150 | 2150 | 2150 | ||
| 17 | Turning radius | mm | 2320 | 2320 | 2380 | 2380 | ||
| 18 | Min. right angle aisle width | mm | 1910 | 1910 | 2000 | 2000 | ||
| 19 | Travel speed (unload/full load) | km/h | 20/18.5 | 20/18.5 | 20/18.5 | 20/18.5 | ||
| 20 | Lift speed (unload/ full load) | mm/s | 510/450 | 510/450 | 510/450 | 510/450 | ||
| 21 | Max. gradeability | % | 20 | 20 | 20 | 20 | ||
| 22 | Tires | Front | 7.00-12-12PR | 7.00-12-12PR | 7.00-12-12PR | 7.00-12-12PR | ||
| 23 | Rear | 6.00-9-10PR | 6.00-9-10PR | 6.00-9-10PR | 6.00-9-10PR | |||
| 24 | Tread | Front | mm | 970 | 970 | 970 | 970 | |
| 25 | Rear | mm | 980 | 980 | 980 | 980 | ||
| 26 | Wheelbase | mm | 1650 | 1650 | 1650 | 1650 | ||
| 27 | Min. ground clearance (unload/ full load) | Mast | mm | 160/140 | 160/140 | 160/140 | 160/140 | |
| 28 | Frame | mm | 150/130 | 150/130 | 150/130 | 150/130 | ||
| 29 | Battery | v/ah | 12/90 | 12/90 | 12/90 | 12/90 | ||
| 30 | Engine | Model | C240 | C490BPG-262 | C240 | C490BPG-262 | ||
| 31 | Rated output | kw/r.p.m | 35.4/2500 | 40/2650 | 35.4/2500 | 40/2650 | ||
| 32 | Rated torque | n.m/r.p.m | 139/1800 | 148/1800 | 139/1800 | 148/1800 | ||
| 33 | Displacement | cc | 2369 | 2540 | 2369 | 2540 | ||
| 34 | No. of cylinder | 4 | 4 | 4 | 4 | |||
| 35 | Bore×stroke | mm | 90×100 | 90×100 | 90×100 | 90×100 | ||
| 36 | Transmission | Model | Hydraulic | Hydraulic | Hydraulic | Hydraulic | ||
| 37 | Shift (FWD/RVS) | 1/1 | 2/2 | 1/1 | 2/2 | |||
| 38 | Operating pressure | mpa | 17.5 | 17.5 | 17.5 | 17.5 | ||
