60kva 3 Phase Generator , 48kW Diesel Generator Enclosed 4DX23-78D
60kVA 48kW 3 Phase Diesel Generator Enclosed 4DX23-78D FAWDE Generator
Commercial FAWDE 60kVA Generator
,4DX23-78DEngine Diesel Generator
,CE FAWDE 60kva Generator ,50HZ
Ⅰ. PRODUCT DESCRIPTION
Fawde China engine, we have all series from 15kva to 413kva. Fawde generator is famous as high quality. Fawde series Genset is characterized by high quality, high efficiency, low vibration and noise, smooth running, high reliability, easy handling. It widely used in national defense, telecommunications, construction site, commercial buildings, industrial and mining sites, oil fields, roads, ports, villas, banks, hospitals etc. and hot-selling to Philippine, Vietnam, Myanmar, Cambodia, Uzbekistan, Kazakhstan, Russia, Africa, etc.
For example:
Healthcare,Data Centers,Telecommunications,Construction,Manufacturing,Oil and Gas,Military,Residential electricity.
Advantages:
Reliable Performance: The Fawde engine is known for its reliable performance, making it an ideal choice for powering your generator. With its low fuel consumption and long maintenance intervals, you can rely on this generator to provide stable and uninterrupted power for extended periods.
High Efficiency: Our generator with Fawde engine is designed to provide high efficiency and low fuel consumption, which can save you money in the long run. With its advanced control system, this generator can adjust its output according to the load demand, ensuring that it operates at maximum efficiency at all times.
Product parameters:
Specification:
| Model | DE-F66 | |
| Max. Power | kVA | 69.0 |
| kW | 55.0 | |
| Rate Power | kVA | 63.0 |
| kW | 50.0 | |
| Frequency | Hz | 50 |
| Rate Voltage | V | 400/230 |
| Rate Current | A | 90.2 |
Technical Data of Fawde Diesel Engine:
| Engine Manufacturer | Faw Jiefang Automotive Co., Ltd. Wuxi Diesel Engine Works | |
| Engine Brand | Fawde | |
| Engine Model | 4DX23-78D | |
| No. of Cylinder | 4 Cylinder in line | |
| Aspiration | Turbocharged | |
| Governor | Electric | |
| Engine Max. Output Power | kW | 63 |
| Displacement | L | 4.750 |
| Starting Voltage | V | 24 |
| Bore | mm | 110 |
| Stroke | mm | 125 |
| Lubrication Oil Capacity | L | 16 |
| Compression Ratio | 17.5 : 1 | |
| Intake Air Flow | M3/Min | 12.3 |
| Fuel Consumption at 100% Load | L/H | 14.8 |
Technical Data of Control Panel for 30kVA Fawde Diesel Generator:
| Controller Brand and Original | ComAp Made in Czech | |
| Breaker Brand | Delixi | |
| Breaker Capacity | A | 125 |
| Battery Charger | Smartgen | |
| Emergency Stop Button | Supply | |
| Automatic Mains Fail (AMF) | Supply | |
| Fuel Level | Supply | |
| Automatic Transfer Switch | ATS as optional part | |
| Mains Monitor | Supply with DELLENT Function | |
| The control panel supply the full protection with alarm and shutdown of the diesel generator include Start-up fault (generator set shutdown), High coolant temperature (alarm and generator set shutdown), Low oil pressure (alarm and generator set shutdown), Low fuel level (alarm), Low cooling fluid level alarm (as optional), Overload (alarm and generator set shutdown), Battery voltage high (alarm). | ||
| Optional controller: Each model of Deepsea, Smartgen, ComAp brand controller. | ||
