Three Phase SDEC Diesel Generator 138kVA Standby Power Diesel Generator
Three Phase SDEC Engine 138kVA Standby Power Diesel Generator
Ⅰ.PRODUCT DESCRIPTION
138kVA Standby Power SDEC Genset Soundproof Engine By 4 Cylinder In Line.Dellent Power supply the standby power 138kVA water cooled diesel generator with SDEC brand diesel engine model SC4H180D2. The water cooled diesel generator with rated output 125kVA /100kW, standby power138kVA /110kW.
138kVA Diesel Generator Powered by SDEC Diesel Engine:
| Model | DE-SC138SC | |
| Prime Power | kVA | 125 |
| kW | 100 | |
| Standby Power | kVA | 138 |
| kW | 110 | |
| Frequency | Hz | 50 |
| Rate Voltage | V | 400/230 |
| Rate Current | A | 199.19 |
Specification of the Diesel Engine:
| Engine Manufacturer | Shanghai Diesel Engine Co., Ltd. | |
| Engine Brand | SDEC | |
| Engine Model | SC4H180D2 | |
| No. of Cylinder | 4 Cylinder in line | |
| Aspiration | Turbocharged | |
| Governor | Electric | |
| Engine Max. Output Power | kW | 132 |
| Displacement | L | 4.300 |
| Starting Voltage | V | 400 |
| Bore | mm | 105 |
| Stroke | mm | 124 |
Specification of Automatic Control Panel:
| Controller Brand | ComAp | |
| Breaker Brand | Delixi | |
| Breaker Capacity | A | 63 |
| Battery Charger | Smartgen Model BAC06A | |
| Emergency Stop Button | Supply | |
| Automatic Mains Fail (AMF) | Supply | |
| Fuel Level | Supply | |
| Automatic Transfer Switch | ATS as optional part | |
| Mains Monitor | Supply with DELLENT Function | |
| The control panel supply the full protection with alarm and shutdown of the diesel generator include Start-up fault (generator set shutdown), High coolant temperature (alarm and generator set shutdown), Low oil pressure (alarm and generator set shutdown), Low fuel level (alarm), Low cooling fluid level alarm (as optional), Overload (alarm and generator set shutdown), Battery voltage high (alarm). | ||
| Optional controller: Each model of Deepsea, Smartgen, ComAp brand controller. | ||
Ⅱ. Why Choose Us:
Ⅲ. QUALIFICATION CENTIFICATE:
Ⅳ. FACTORY INTERIOR:
1.When diesel generators are not used for a long time, regular maintenance and inspection should be carried out to ensure their normal operation;
2: Diesel generators should use dry air to avoid malfunctions caused by high humidity;
3: Diesel generators should avoid long-term low load operation to avoid affecting the performance of the diesel engine;
4: Diesel generators should be avoided in high-altitude areas to avoid affecting the performance of the diesel engine;
