DP158LC 50Hz 450kVA Diesel Generator , Doosan Standby Generator
Ⅰ.PRODUCT DESCRIPTION
Don't settle for less when it comes to your power needs. Choose a Doosan generator from our dealership today and experience the power and reliability that only Doosan can offer. Contact us to learn more about our Doosan generators and services. Doosan generator with international Warranty Service
Product parameters:
Specification of 450kVA Emergency Standby Generator:
| Model | DE-DS450 | |
| Max. Power | kVA | 500 |
| kW | 400 | |
| Rate Power | kVA | 450 |
| kW | 360 | |
| Frequency | Hz | 50 |
| Rate Voltage | V | 415/240V |
| Rate Current | A | 626.0 |
| Fuel Tank Capacity | L | 600L |
| Dimension For Open-type Genset | mm | 3050 X 1400 X 1980 |
| Weight For Open-type Genset | kg | 4000 |
| Dimension For Soundproof Genset | mm | 4350 X 1450 X 2180 |
| Weight For Soundproof Generator | kg | 5100 |
| Noise Level for Soundproof Generator at 7M | dBA | 78 |
Specification of Doosan Diesel Engine DP158LC:
| Engine Manufacturer | Doosan Infracore | |
| Engine Brand | Doosan | |
| Engine Model | DP158LC | |
| No. of Cylinder | 8 Cyliner V Type | |
| Aspiration | Turbocarged & Aftercooed | |
| Governor | Electric | |
| Engine Max. Output Power | kW | 449 |
| Displacement | L | 14.6 |
| Compression Ratio | 15 : 1 | |
| Starting Voltage | V | 24 |
| Bore | mm | 128 |
| Stroke | mm | 142 |
| Lubrication Oil Capacity | L | 28 |
| Intake Air Flow | M3/Min | 25.3 |
| Fuel Consumption at 100% Load | L/H | 100.8 |
Specification of Control Panel :
Specification of Control Panel for 450kVA Emergency Standby Generator:
| Controller Brand | Smartgen | |
| Controller Model | HGM6120N | |
| Breaker Brand | Delixi | |
| Breaker Capacity (A) | 800 | |
| Emergency Stop Button | Supply | |
| Automatic Mains Fail (AMF) | Supply | |
| Fuel Level | Supply | |
| Automatic Transfer Switch | ATS as optional part | |
| The control panel supply the full protection with alarm and shutdown of the diesel generator include Start-up fault (generator set shutdown), High coolant temperature (alarm and generator set shutdown), Low oil pressure (alarm and generator set shutdown), Low fuel level (alarm), Low cooling fluid level alarm (as optional), Overload (alarm and generator set shutdown), Battery voltage high (alarm). | ||
| Optional controller: Each model of Deepsea, Smartgen, ComAp brand controller. | ||
Ⅱ. Why Choose Us:
Ⅲ. QUALIFICATION CENTIFICATE:
Ⅳ. FACTORY INTERIOR:
FAQ
Q: What's your delivery time?
A: Standard product 20 days - 30 days.
Q: Can we add our logo to products?
A: Yes, there are several ways to do this. We can put the label of your logo on the products or make the silk print of your logo on the products. It is free.
Q: Can we customize the product?
A: We have a very experienced technical team, we can customize any product according to your requirements, such as synchronization system, wet exhaust system, ultra-silent system
