1.2ton Mini Hydraulic Crawler Excavator
Introductions Of 1.2ton Mini Hydraulic Crawler Excavator
ZM12 Mini Excavator - Unleashing Power and Efficiency in a 1.2-ton Package.
With its increased lifting capacity and enhanced digging force, this mini excavator is built to tackle a variety of projects with ease.
The ZM12 boasts a compact design for maneuvering in confined spaces while delivering exceptional performance.
Equipped with advanced hydraulic technology and a digging depth of 1700mm, it ensures precise and efficient excavation.
Whether it's landscaping, construction, or utility work, the ZM12 Mini Excavator offers the power and versatility needed to get the job done efficiently.
Experience the next level of productivity with the ZM12 Mini Excavator.
Parameters Of 1.2ton Mini Hydraulic Crawler Excavator
| ZM12 | |||||
| Overall dimensions | Scope of work | Complete machine configuration | |||
| Total length | 2770mm | Maximum excavation height | 2620mm | Work quality | 0.85T |
| Overall width | 920mm | Maximum unloading height | 1820mm | engine | Youpu, Science Popularization, Changchai, Bailitong |
| Total height | 1520mm | Maximum excavation depth | 1700mm | emission standard | China II, Europe V |
| Track width | 915mm | Maximum excavation radius | 2945mm | Engine model | 192F |
| Platform ground clearance | 370mm | Stick digging force | 4Kn | Engine power | 7.6KW/3000rpm |
| track width | 180mm | Bucket digging force | 6Kn | Fuel tank volume | 6L |
| Track Height | 320mm | Maximum digging force | 7Kn | Main pump displacement | 6.5mL/r |
| Transportation length | 2810mm | Bucket volume | 0.025m³ | Hydraulic oil tank volume | 13L |
| Maximum lifting height of bulldozer blade | 315mm | Travel speed | 2.5km/h | working pressure | 16MPa |
| Maximum cleaning depth of bulldozer | 265mm | Gradeability | 30° | Mode of operation | Connection and unloading operation |
| Minimum turning radius of tail | 1300mm | ||||
Photos Of 1.2ton Mini Hydraulic Crawler Excavator
