ASTM A249 TP304 Wound L Type Tube For Bolier Heat Exchanger
ASTM A249 TP304 Wound L Type Tube For Bolier Heat Exchanger
ASTM A249 TP304 has excellent corrosion resistance in ordinary atmospheric conditions, making it suitable for a wide range of applications where exposure to corrosive environments is a concern.This material has high ductility and excellent drawing, forming, and spinning properties, which makes it easy to shape and form into various configurations as required for different applications.ASTM A249 TP304 is designed to withstand high temperatures and pressures, making it suitable for use in boilers, condensers, heat exchangers, and other critical applications where extreme conditions are common.
1.Singificant Advantages:
- Enhanced Heat Transfer Efficiency
- Improved System Performance
- Material Compatibility
- Cost-Effectiveness
- Corrosion Protection
2. Chemical Composition:
| Chemical Composition | |||||||
| C | Si | Mn | P | S | Cr | Ni | Fe |
| ≤ 0.08% | ≤ 1.00% | ≤ 2.00% | ≤ 0.045% | ≤ 0.030% | 18.0 - 20.0% | 8.0 - 11.0% | Balance |
3.Mechanical Properties:
| Mechanical Properties | |||
| Tensile Strength (min) | Yield Strength (min) | Elongation in 2" or 50 mm (min) | Hardness, Max |
| 515 MPa [75 ksi] | 205 MPa [30 ksi] | 35% | 90HB |
4.Application area:
- Corrosive Environments
- Air Coolers
- Food Industry
- Power Plants
