Carbon Steel A179 Extruded Fin Tubes With AL1060 Fins Tubos Aletados For Radiadores

Extruded Fin Tubes Carbon Steel A179 With AL1060 Fins Tubos Aletados For Radiadores

Base Tube Destails ( Generally with min. wall thickness )

ASTM A179 This specification covers minimum-wall-thickness, seamless cold-drawn low-carbon steel tubes for tubular heat exchangers, condensers, and similar heat transfer apparatus.

Chemical Composition (%) max

Mechanical Properties

Definition

Extruded finned tubes are bimetallic tubes whose outer aluminium surface is finned by cold plastic deformation.The general materials of base tubes about the extruded finned tube are carbon steel, copper, alloy, stainless steel ; the general materials of fins about the extruded finned tube are copper, aluminum 1060/1070, aluminum alloy 6063/6061.

Therefore, it is generally divided into four categories: steel aluminum composite finned tubes; copper aluminum composite finned tubes; pure aluminum composite finned tubes, pure copper composite finned tube.

Advantages

Composite finned tubes have the following characteristics:

1. High heat transfer performance, small contact thermal resistance;

2. The contact area between the fin and the pipe is large, the fit is tight and reliable;

3. Good corrosion resistance, stable long-term use performance;

4. highly cost effective;

5. The fin has good rigidity and is not easy to deform.

The processing technology of steel and aluminum cold-rolled fin tube consists of aluminum tube and steel pipe being processed into bimetal composite tube, and then forming fin after mechanical cold rolling. Based on the physical characteristics of aluminum tube, the tube with steel tube as the core and the cold rolled aluminum fin are made into a finned tube. Widely used in steel, petroleum, chemical industry, machinery, shipbuilding, power stations and hospitals and food industries.
