Extruded Finned Tubes Carbon Steel Tube ASTM A179 With Aluminum 1060 Fins For Condensers And Air Coolers
- YUHONG brand goods have been already exported to more than 85 countries With more than 35 years' experience, because of strict quality control policy, excellent sales service, delivery on time. YUHONG won more and more new clients and got more and more repeat orders from old clients, in YUHONG People's mind: Quality is First Important!
Extruded Finned Tubes ASTM A179 With Aluminum 1060 Fins For Consensers and Air Coolers Introduction
An Extruded Finned Tubes ASTM A179 With Aluminum 1060 Fins is a specialized heat exchanger component designed to enhance heat transfer efficiency. It consists of a base tube made of ASTM A179 minimum-wall-thickness, seamless cold-drawn low-carbon steel and fins made of Aluminum 1060, which are are formed by extruding heated metal through a die to simultaneously shape the base tube and fins in a single seamless process, enhancing heat transfer and mechanical strength.
1.Chemical & Mechanical Properties
| ASTM A179 Chemical Composition (%) | |||||
| C | Mn | P | S | Si | Fe |
| ≤ 0.06 - 0.18% | 0.27 - 0.63% | ≤ 0.035% | ≤ 0.035% | ≥ 0.10% (typically 0.25-0.50%) | Balance (≥ 98%) |
| Aluminum 1060 Fins Chemical Composition (%) | ||||||
| Al | Fe | Si | Cu | Mn | Zn | Else |
| ≥ 99.60% | ≤ 0.35% | ≤ 0.25% | ≤ 0.05% | ≤ 0.03% | ≤ 0.05% | ≤ 0.40% |
Mechanical Properties
| Component | Mechanical Performance | Key Features |
| ASTM A179 Base Tube |
· Tensile Strength: ≥325 MPa · Yield Strength: ≥180 MPa · Elongation (in 50mm): ≥35% · Hardness: ≤ 72HRB |
· Precision cold-drawn seamless tubing for minimum wall thickness · Thermal Conductivity: 52 W/m·K at 20°C · Superior resistance to oxidation and water corrosion · Maximum Operating Temperature: 450°C (843°F) for continuous service · Moderate strength: Suitable for low/medium-pressure heat exchangers. |
| Aluminum 1060 Fins | · Tensile Strength: 70-110 MPa · Elongation: 15-25% · Hardness: 23 HB. |
· Lightweight Design Reduces System Load · Ductile For Vibration Absorption |
2. Key Feature
(1) Ultra-high heat transfer efficiency
3-8x higher heat transfer vs. bare tubes
(2) Mechanical strength and lightness
Weight reduction: 40-60% Pressure bearing capacity
Pressure bearing capacity: 6.9MPa
(3) Anti-corrosion double insurance
A179 base tube for water corrosion resistance + optional anodized aluminum fins
(4) Vibration resistance
Fins are integrally formed and have zero looseness
3. Key Applications
(1) Power & Energy
Air-cooled condensers in thermal power plants
Waste heat recovery from gas turbine exhaust
Auxiliary cooling systems for nuclear power plants
(2) Petrochemical
Heat exchangers in crude oil distillation units
Cooling of cracked gas in ethylene production
Sulfuric acid plant gas cooling systems
(3) Industrial Manufacturing
Aftercoolers for industrial compressed air systems
Hydraulic oil cooling in plastic injection molding machines
Rolling mill lube oil coolers in steel plants
(4) Transportation & Marine
Central seawater coolers for marine engines
Cooling of traction converters in high-speed trains
Battery thermal management systems for EVs
