ASTM A213 T5 G-Type Embedded Finned Tubes High Performance for Industrial Heat Exchange

Price Negotiable

Price: Negotiable

MOQ: 100 KGS

Delivery Time: 20-80 days

Brand: Yuhong

Product Description

ASTM A213 T5 G-Type Embedded Finned Tubes: High - Performance for Industrial Heat Exchange

1. Product Overview

Yuhong Holding Group Co., Ltd presents the ASTM A213 T5 G-Type Embedded Finned Tubes, engineered for superior heat transfer in industrial systems. With 20 years of export expertise to 80+ countries and a top - 5 position in China’s finned tube export market, we ensure quality backed by 55 production lines, 110+ skilled workers, and a 20,000㎡ advanced facility.

2. Material & Chemical Composition

Base Tube: ASTM A213 T5 Alloy Steel

The core strength lies in the ASTM A213 T5 alloy steel base tube. Its chemical composition ensures high - temperature stability and corrosion resistance:

Element	C	Mn	P	S	Si	Cr	Ni
% Max	0.15 max	0.3-0.6	0.035 max	0.03 max	0.1-0.3	4-6	-

Fins: High - Quality Aluminum Alloys

Fins are typically made of aluminum alloys (e.g., 1050, 3003 series), chosen for excellent thermal conductivity. Custom fin materials are available per project requirements.

3. Mechanical Properties

Designed to withstand industrial heat - exchange stresses, the tubes offer:

Property	Value
Tensile Strength	≥415 MPa
Yield Strength	≥205 MPa
Elongation	≥30%

4. Processing Technology

Our G-Type embedded finned tubes undergo a precision - engineered process:

Base Tube Preparation: ASTM A213 T5 tubes are cut, cleaned, and prepped for fin embedding.
Fin Embedding: Aluminum fins are mechanically embedded into precision - machined grooves on the base tube. This ensures a tight, gap - free bond for maximum heat transfer.
Heat Treatment: Optional post - processing heat treatment (per ASTM A213 standards) enhances material uniformity and strength.
Quality Control: 100% NDT (Non - Destructive Testing) checks for fin integrity, tube thickness, and structural flaws.

5. Performance & Application Scenarios

Thermal Performance

The embedded fin design boosts heat transfer efficiency by 25 - 40% compared to standard finned tubes. This is critical for:

Petrochemical Plants: Cooling process fluids, condensing vapors.
Power Generation: Heat recovery in boilers, turbine systems.
Refrigeration & HVAC: Optimizing condenser/evaporator efficiency.

6. Product Advantages

Superior Heat Transfer: Embedded fins minimize thermal resistance, ensuring rapid heat exchange.
Durability: ASTM A213 T5 base tubes resist high temperatures (up to 600°C) and corrosion; embedded fins avoid detachment.
Customization: Tailor fin height, density, and material to your system’s needs (e.g., harsh - environment alloys).
Cost - Efficiency: Reduced energy consumption due to high efficiency lowers long - term operational costs.

7. FAQ

Q1: Can these tubes be used in corrosive environments?
A: Yes. ASTM A213 T5 offers good corrosion resistance, and we can further customize fin/tube materials (e.g., stainless steel fins) for extreme conditions.

Q2: What is the maximum operating temperature?
A: The tubes safely operate up to 600°C; for higher temps, contact us for custom alloy solutions.

Q3: Do you provide installation support?
A: Yes! Our team offers technical guidance, and we can connect you with local partners for on - site assistance.

8. About Yuhong Holding Group Co., Ltd

With 20 years of global export experience (serving 80+ countries), Yuhong is a leader in China’s finned tube industry. Our 55 production lines, 110+ skilled workers, and 20,000㎡ factory—equipped with advanced CNC machinery and quality labs—guarantee products that meet international standards (e.g., ASTM, ASME).

We prioritize:

Quality: ISO 9001 - certified processes.
Service: 24/7 technical support, on - time delivery.

9. Contact Us

Ready to upgrade your heat - exchange systems? Reach out:

Email: jimmy@steelseamlesspipe.com
WhatsApp: +86 18892647377
Website: www.steelfintube.com

Choose Yuhong’s ASTM A213 T5 G-Type Embedded Finned Tubes for reliability, efficiency, and industrial - grade performance. Your heat - exchange challenges, solved.
