24V 100Ah LiFePO4 Battery Pack

This 24V lifepo4 battery can achieve more than 6000+ cycles, which lasts up to 4 times longer than a lead-acid battery battery. The inside BMS can automatically stop recharging under the temperature of 0 ℃ and also can prevent the battery from the most common issue, such as temperature volatility, overcharge, over-discharge, over-current, overloading, overheating. This 24V lifepo4 battery can widely run your golf cart, RV, motorhome, boat, marine, camper, Caravan, electric forklift, trolling motor, electric motorcycle and so on.

Battery Performance

• Nominal Voltage:25.6V

• Nominal Capacity:100Ah

• Nominal Energy:2560Wh

• Internal Resistance:≤20mΩ @ 50% SOC

• Self Discharge:<3% / Month

Charge Performance

• Recommended Charge Current:20A

• Maximum Charge Current:≤50A

• Recommended Charge Voltage:28.8V

• BMS Charge Cut-Off Voltage:<29.2V(3.65V/Cell)

• Reconnect Voltage:>28.4V(3.55V/Cell)

• Balancing Voltage:<28.2V(3.525V/Cell)

Discharge Performance

• Maximum Continuous Discharge Current:25A

• Peak Discharge Current:≤100A(≤5S)

• BMS Discharge Cut-Off Current:150A ±10A(50-150ms)

• Recommended Low Voltage Disconnect:18.4V(2.3V/Cell)

• BMS Discharge Cut-Off Voltage:>18.4V (2s) (2.3V/Cell)

• Reconnect Voltage:>21.6V (2.7V/Cell)

• Short Circuit Protection:450 ~ 800 μs

Temperature Performance

• Discharge Temperature:-40 ~ 131 ºF (-40~ 55 ºC)

• Charge Temperature:-40~ 131 ºF (-40~ 55 ºC)

• Storage Temperature:23 ~ 95 ºF (-5 ~ 35 ºC)

• BMS High Temperature Cut-Off:149 ºF (65 ºC)

• Reconnect Temperature:131 ºF (55 ºC)
