Heat Curing Dry Film Lubricant Coating Molykote 106 Composed Of Solid Lubricants
Molykote 106 is a heat-curing dry film lubricant coating composed of solid lubricants.
Product Properties
Molykote 106 is a heat-curing dry film lubricant coating composed of solid lubricants, organic binders, and solvents. It features a low coefficient of friction, high load-carrying capacity, excellent adhesion, and contains no intentional PTFE or PFAS substances.
| Parameter | Test Standard | Unit | Result | Condition |
|---|---|---|---|---|
| Color | - | - | Dark gray | Visual |
| Viscosity (20°C) | DIN EN ISO 2431 | s | 37 | ISO4 cup |
| Density (20°C) | DIN 53217/2 | g/ml | 1.16 | - |
| Flash Point | DIN ISO 2619 | °C | 29.5 | - |
| Curing Time | - | min | 60 (150°C) | Object temperature |
| - | min | 30 (180°C) | Object temperature | |
| Service Temperature | - | °C | -70 to +250 | - |
| Falex Load Capacity | - | N | 14,500 | Phosphatized surface[2] |
| LFW-1 Rotating μ=0.1 | ASTM D2714 | - | p=478[2] | 2,860N, 72 rpm |
| LFW-1 Oscillating μ=0.08 | ASTM D2714 | - | p=292[2] | 900N, 89.5 osc/min |
Molykote 106 forms a durable lubricating film through thermal curing, providing maintenance-free lubrication for metal/metal combinations. Designed for applications where oils/greases are impractical or contamination must be avoided, it excels in highly stressed, low-speed, or oscillating operations.
Enhanced Properties
• Eco-Safe: PFAS/PTFE-free formulation aligns with modern environmental standards;
• Longevity: 5-20μm dry-film thickness withstands -70°C to 250°C;
• Process Flexibility: Applicable by spraying, dipping, centrifuging, or brushing; phosphating/sandblasting pretreatment enhances service life.
Application Scenarios
- Beyond TDS-stated locks/hinges/engine coatings, industrial applications include:
- Turbocharger linkage pivots in automotive systems
- Gear surfaces in robotic reducers
- Bearing sealing faces on marine rudder systems
Specification
|
item
|
value
|
|
Place of Origin
|
usa
|
|
Brand Name
|
Molykote
|
|
Type
|
Greases
|
|
Model Number
|
106
|
|
specifications
|
5kg
|
