Non Silicone Heat Transfer Compound Electrolube HTCX For Electronic Heat Dissipation

Price Negotiable

Price: CN¥1,006.30/pieces >=1 pieces

MOQ: 1

Delivery Time: 5-8days

Brand: Electrolube

Product Description

Electrolube HTCX Non-Silicone Thermal Paste for Efficient Electronic Heat Dissipation

Product Properties

Property	Value
Colour	White
Base	Blend of synthetic fluids
Thermo-conductive Component	Powdered metal oxides
Density @ 20°C (g/ml)	2.61
Cone Penetration @ 20°C	300
Viscosity at 1rpm (Pa s)	127-141
Thermal Conductivity (Guarded Hot Plate)	1.35 W/m·K (calculated)
Thermal Conductivity (Heat Flow)	0.90 W/m·K
Temperature Range	-50°C to +180°C*
Weight Loss after 96 hours @ 100°C	<0.40%
Permittivity @ 1 GHz	4.2
Volume Resistivity	1 × 10¹⁴ Ohms-cm
Dielectric Strength	42 kV/mm

Product Introduction

Electrolube HTCX is a high-performance, non-silicone heat transfer compound designed as an enhanced version of HTC, featuring improved thermal conductivity, lower oil bleed, and reduced evaporation weight loss. It serves as a reliable thermal interface material for efficient heat dissipation between surfaces, ideal for applications where silicones are prohibited to avoid issues with silicone migration. The paste is non-curing, enabling easy rework of components, and is approved for RoHS compliance (2015/863/EU).

Enhanced Properties

The thermal conductivity values vary based on measurement methods: the guarded hot plate method yields a calculated 1.35 W/m·K, while the heat flow method provides a more accurate 0.90 W/m·K due to accounting for surface resistance. Key attributes include excellent stability under varying temperature and humidity, low weight loss (<0.40% after 96 hours at 100°C) indicating minimal degradation, and high electrical insulation properties (volume resistivity of 1 × 10¹⁴ Ohms-cm and dielectric strength of 42 kV/mm). The density of 2.61 g/ml and viscosity range of 127-141 Pa·s ensure easy application, but performance depends on achieving a thin, uniform film to maximize heat flow efficiency.

Application Scenarios

Electrolube HTCX is specifically used for thermal management in electronic components such as diodes, transistors, thyristors, heat sinks, silicone rectifiers, semiconductors, thermostats, power resistors, and radiators, as detailed in the TDS "Directions for Use" section. Online sources (e.g., Electrolube official website and distributor datasheets) confirm its application in CPU/GPU cooling, power electronics, automotive sensors, and industrial equipment where non-silicone thermal paste is required to prevent contamination and ensure efficient heat dissipation under harsh conditions.
