Electrolube PUC Polyurethane Coating For Electronic Circuit Protection

Price Negotiable

Price: CN¥132.39/pieces 1-499 pieces

MOQ: 1

Delivery Time: 5-8days

Brand: Electrolube

Product Description

Electrolube PUC Polyurethane Coating for Electronic Circuit Protection

Product Properties

Property	Value
Appearance	Clear amber liquid
Density @ 20°C	0.90 g/ml (Bulk), 0.870 g/ml (Aerosol)
VOC Content	63% (Bulk), 66% (Aerosol)
Flash Point	38°C (Bulk), -4°C (Aerosol)
Solids Content	37% (Bulk), 34% (Aerosol)
Viscosity @ 20°C	150-240 mPa s
Touch Dry Time	40-45 minutes
Recommended Drying Time	24 hours @ 20°C, 180 minutes @ 65°C, 90 minutes @ 80°C
Coverage @ 25μm	14 m² per litre (Bulk), 5 m² (400ml Aerosol)
Operating Temperature Range	-55°C to +130°C
Flammability	Meets UL94-V0
Dielectric Strength	60 kV/mm
Dielectric Constant	3.6
Surface Insulation Resistance	1x10¹⁵ Ω
Dissipation Factor @ 1MHz, 25°C	0.01
Approvals	RoHS Compliant (2015/863/EU), MIL Approval (MIL-1-46058C), IPC-CC-830, DEF-STAN 59/47

Product Introduction

Electrolube PUC is a tough, flexible, modified polyurethane conformal coating specifically designed for the protection of electronic circuitry. It offers excellent mechanical and dielectric properties, ensuring reliable performance in various environments. The coating can be applied via spraying, dipping, or brushing methods, with recommended drying conditions to achieve optimal results.

Enhanced Properties

PUC exhibits high abrasion resistance and solvent resistance even at room temperature curing, making it ideal for robust applications. It features excellent adhesion across a wide temperature range (-55°C to +130°C), protecting against thermal shocks. Additionally, it has a low coefficient of expansion (100ppm), high dielectric strength (60 kV/mm), and meets MIL standards for moisture resistance and thermal cycling. The coating is reworkable using Electrolube CCRG, enhancing its usability in critical electronic assemblies.

Application Scenarios

Electrolube PUC is primarily used for conformal coating on printed circuit boards (PCBs) to protect against environmental hazards such as moisture, dust, chemicals, and temperature fluctuations. Based on TDS, it is suitable for electronic circuitry protection in general applications. Online searches for specific scenarios (e.g., automotive or aerospace) using the exact model PUC yielded no additional verified data; thus, the application is limited to PCB protection as described in the TDS.
