Standard Fiberglass Roving Yarn Corrosion Resistant For Mat Production
Price:
$0.42-$1.13（KG）
MOQ:
5000KGS
Delivery Time:
3-7 work days
Brand:
WGSC
Product Description
Fiberglass Roving Yarn For Mat Production High Performance Reinforcement Solutions
| Attribute | Value |
|---|---|
| Model Number | ER2400 |
| Linear Density Tex | 2400 |
| Moisture Content | ≤ 0.2% |
| Tolerance | ±6% |
| Size Content | 0.50±0.20% |
| Stiffness mm | 110±15% |
Core Advantages
- Superior Processability: Optimized chopability & dispersion with controlled stiffness; minimal fuzz and static generation
- Enhanced Resin Compatibility: ≤50s resin impregnation time; full compatibility with UP/VE/epoxy resins for high-transparency laminates
- Mechanical Excellence: Tensile strength ≥0.40 N/tex (S-1HM grade), improving composite interlaminar shear strength by 25%
Industrial Applications of Fiberglass Roving Yarn
| Sector | Critical Use Cases | Reinforcement Formats |
|---|---|---|
| Construction | Translucent panels, wall reinforcement | Chopped Strand Mat (CSM), Stitched Mat |
| Transportation | Automotive bumpers, train interiors | Multiaxial fabrics, PP core composites |
| Renewable Energy | Wind turbine spar caps, corrosion-resistant ducts | Biaxial fabrics, unidirectional rovings |
| Industrial Equipment | Chemical tanks, filtration media | Surface veils, needle-punched mats |
Technical Specifications: Fiberglass Roving Yarn Data Sheets
Standard Roving Yarn Grades
| Parameter | E-Glass Standard | C-Glass (Acid-Resistant) | S-1HM (High Modulus) | Test Standard |
|---|---|---|---|---|
| Glass Composition | E-Glass | C-Glass | S-1HM | ISO 2078 |
| Tex Range (g/km) | 600-4800 | 600-9600 | 2400-9600 | GB/T 18371 |
| Filament Diameter | 13-17 μm | 11-17 μm | 13-17 μm | ASTM D578 |
| Tensile Strength | ≥0.30 N/tex | ≥0.35 N/tex | ≥0.40 N/tex | ASTM D2343 |
| Moisture Content | ≤0.20% | ≤0.20% | ≤0.20% | ASTM D1576 |
Customization Support:
- Tex: 200-9600 (direct/assembled roving)
- Sizing: Silane/epoxy/starch binders for resin compatibility
Specialty Yarns for Critical Environments
| Product Code | Type | Linear Density | Twist (T/m) | Temp Resistance | Primary Application |
|---|---|---|---|---|---|
| EC13-136S30 | E-Glass Twisted | 136 tex | S30 | 550°C | Electrical insulation |
| CC11-100S30 | C-Glass Twisted | 100 tex | S30 | 500°C | Acid filtration cloth |
| ET9-2800 | Bulked Yarn | 2800 tex | N/A | 550°C | Fire blankets, insulation |
Industrial Packaging & Logistics
- Unit Packaging:
- 19-kg roving coils sealed in anti-static PE bags (humidity barrier ≥95%)
- Coil dimensions: Ø30×25 cm (customizable)
- Bulk Handling:
- Palletized: 64 coils vertically per pallet (120×100×15 cm; max. 2 layers)
- Carton Option: 1 coil/5-ply corrugated box (max. stack: 5 layers; ≤50kg/box)
- Container Load:
- 40HQ capacity: 18-22 pallets (≈25 tons)
Storage Protocols per ASTM D3656
- Environmental Control:
- Temperature: 10-30°C (＜5°C causes brittleness; ＞40°C degrades sizing)
- Humidity: 35-65% RH (＞85% RH impacts moisture content & curing)
- Shelf Life:
- Unopened: 12 months from production date
- Opened coils: Use within 72 hours (reseal with heat-sealed bags)
Value-Added Services
- Custom Yarn Design: Adjust glass type (E/C/S-1HM), tex, twist (S/Z direction), sizing chemistry
- Certified Testing: ISO 14130 shear strength reports (≥25 MPa) & resin wettability data
- Global Compliance: DNV-GL/CE-certified shipments with real-time humidity tracking
