Chemical Resistant Fiberglass Roving Yarn Electrical Insulation For Construction Mesh
Price:
$0.42-$1.13（KG）
MOQ:
5000KGS
Delivery Time:
3-7 work days
Brand:
WGSC
Product Description
Fiberglass Roving For Construction Mesh
Product Specifications
| Linear Density | 300-500(tex) |
| Density Tolerance | ±5% |
| Target Application | Construction Mesh |
| Shape | FILAMENT WRAPPING |
| Electrical Insulation | Excellent |
| Chemical Resistance | Excellent |
Product Overview
Specialty fiberglass roving engineered with fluorine-free and boron-free glass technology, precision-designed for weaving processes to reinforce critical building components. Delivers superior performance in demanding construction applications.
Primary Application Sectors
| Application Category | Specific Products | Functional Value |
|---|---|---|
| Wall Reinforcement Systems | External wall insulation mesh, Anti-crack interior wall grids | Prevents structural cracking & enhances seismic resistance |
| Building Material Composites | GRC cement boards, Gypsum board reinforcement layers | Increases flexural strength by 40%+ |
| Decorative Materials | Mosaic backing mesh, Marble backing nets | Prevents decorative material delamination |
| Waterproofing Engineering | Waterproof membrane substrates, Roof moisture barriers | Boosts tensile strength of waterproof layers |
Technical Specifications & Performance Data
Core Performance Advantages
| Property | Technical Performance | Industry Standard |
|---|---|---|
| Yarn Characteristics | Wet-processed strands with ≤0.1% fuzz | ISO 1889 |
| Flexural Endurance | >10,000 bending cycles without fracture | ISO 7854 |
| Interfacial Bonding | Custom sizing agent enhances fiber-matrix adhesion | ASTM D2343 |
Product Grades
| Grade | Linear Density (tex) | Density Tolerance | Target Application |
|---|---|---|---|
| J903 | 300-500 | ±5% | Premium exterior wall insulation mesh |
Customization Service: Available in 400-600 tex for heavy-duty mesh applications
Advanced Packaging System
Multi-Tier Protection Protocol
| Packaging Tier | Technical Specification | Protection Class |
|---|---|---|
| Unit Sealing | PVC shrink film encapsulation | IP65 moisture barrier |
| Pallet Configuration | 4×4 matrix (48 rolls standard, 64 rolls optional) | 1.5-ton load capacity |
| Transport Security | Anti-tilt pallet design | Passes 1.2m drop test |
Specialized Options
- UV-resistant packaging film (for Middle East/tropical regions)
- Reinforced core protectors (prevents deformation)
Scientifically Managed Storage
Storage Control Parameters
| Parameter | Optimal Range | Monitoring Protocol |
|---|---|---|
| Temperature | 15°C-35°C | Climate-controlled warehouse + weekly audit |
| Relative Humidity | Recommended 30%-70%* | Humidity loggers + desiccant packs |
| Stacking Requirements | ≥15cm floor clearance | Plastic pallet isolators |
*Document specifies temperature only; humidity range based on industry best practices
Quality Preservation Measures
- 72-hour usage window after package opening
- Batch-segregated storage with color-coded zones
- Monthly moisture testing (max 0.3% content)
