High Durability Heat Resistant Continuous Roving Fiberglass LFT Direct Roving
Price:
$0.42-$1.13（KG）
MOQ:
5000KGS
Delivery Time:
3-7 work days
Brand:
WGSC
Product Description
LFT Direct Roving Engineering Thermoplastic Reinforcement
Product Specifications
| Attribute | Value |
|---|---|
| Linear Density | 600-2400(tex) |
| Density Tolerance | ±5% |
| Compatible Resin | PP/PE |
| Optimal Process | LFT/Prepreg |
| Shape | FILAMENT WRAPPING |
| Electrical Insulation | Excellent |
Product Overview
Long Fiber Thermoplastic (LFT) direct roving utilizes boron-free & fluorine-free glass technology, engineered for PP/PE resin systems in injection molding and compression molding processes. Delivers superior mechanical performance for structural automotive and industrial applications.
High-Performance Application Sectors
| Industry | Critical Components | Functional Value |
|---|---|---|
| Automotive | Door beam inserts, seat frames, front-end modules | 30% weight reduction, +50% impact resistance |
| Consumer Electronics | AC fan impellers, washing machine counterweights | Noise reduction ≥3dB, enhanced creep resistance |
| Industrial Equipment | Power tool housings, gearbox components | Oil/corrosion resistance, dimensional stability (±0.1mm) |
| Sports Technology | Ski core layers, bicycle pedals | Fatigue resistance >10⁶ cycles |
Technical Specifications & Performance Metrics
Product Differentiation Matrix
| Property | J860 Profile | J859 Profile |
|---|---|---|
| Base Performance | High strength/modulus | Low-VOC emission (<50μg/g) |
| Process Efficiency | Dispersion index ≥95% | 40% faster fiber spreading |
| Compliance | RoHS certified | REACH compliant |
| Fiber-Matrix Bonding | Silane coupling agent enhanced | Fiber exposure <0.5% |
Technical Parameters
| Grade | Linear Density (tex) | Density Tolerance | Compatible Resin | Optimal Process |
|---|---|---|---|---|
| J860 | 600-2400 | ±5% | PP | LFT-D |
| J859 | 600-2400 | ±5% | PP/PE | LFT-G/Prepreg |
Core Process Advantages
- Proprietary sizing ensures fiber-resin adhesion (peel strength ≥80N/cm)
- Minimal product color deviation (ΔE≤0.8 per ISO 105-A05)
-Spec Protection Packaging
5-Tier Defense System
| Protection Tier | Technical Specification | Performance Benchmark |
|---|---|---|
| Primary Unit Seal | Full-wrap PE adhesive film | Scratch/Dust Resistance |
| Secondary Buffer | 360° pearl cotton padding | 50J impact absorption |
| Pallet Matrix | 4×4 configuration (48/64 rolls) | 2-ton load capacity |
| Fiber Continuity | Knot-free air-textured splicing | Breakage rate <1‰ |
| Tertiary Armoring | Corrugated top/bottom covers + side panels + steel straps + multi-layer stretch film | Passes 3G vibration testing |
Smart Warehouse Management Protocol
Environmental Control Standards
| Parameter | Control Range | IoT Monitoring | Non-Conformance Response |
|---|---|---|---|
| Temperature | 15°C-35°C | Wireless sensors | Auto-activate HVAC |
| Humidity | 30%-70% | Precision hygrometers | Trigger dehumidifiers |
| Stacking | ≥20cm floor clearance | Laser positioning | Auto-pallet correction |
Quality Assurance Protocol
- Unopened Shelf Life: 24 months (original packaging)
- Post-Opening Protocol:
- 72-hour usage window
- Vacuum resealing for residuals
- Periodic Audit:
- Monthly moisture testing (≤0.2%)
- Quarterly sizing activity verification
