Industrial Uhmw Synthetic Rope High Longevity Uv Resistant Customized UHMWPE Rope
Price:
$3.52-$11.27(KG)
MOQ:
500KGS
Delivery Time:
3-7 work days
Brand:
WGSC
Product Description
UHMWPE Rope - UHMWPE Material Marine Industrial Rope for Mooring, Lifting & Towing
Product Attributes
| Material | Glass Fiber |
| Fiber Diameter | 13um |
| Tensile Strength | ≥40N/5cm |
| Fiber Type | E-Glass |
| Moisture Content | ≤0.2% |
| Compatible Resin | Polyester, Vinyl Ester, Epoxy |
Product Introduction
Ultra-High Molecular Weight Polyethylene (UHMWPE) rope is a cutting-edge synthetic fiber rope renowned for its exceptional strength-to-weight ratio, corrosion resistance, and durability.
- Lightweight & High Strength: 87.5% lighter than steel cables of the same diameter but 1.5x stronger.
- Abrasion & UV Resistance: Withstands harsh marine environments, including saltwater, UV exposure, and extreme temperatures (-20°C to 70°C).
- Safety & Efficiency: Ideal for maritime applications (mooring, towing), offshore oil platforms, and industrial lifting due to low elongation and high energy absorption.
Manufacturing Process
Our UHMWPE ropes undergo advanced techniques to ensure premium quality:
- Fiber Production: High-strength UHMWPE fibers are extruded via gel-spinning and stretched to enhance molecular alignment.
- Core Formation: 8-strand or 12-strand cores are twisted using high-precision machinery, followed by pre-tensioning to eliminate internal stress.
- Protective Layers: A braided polyester or aramid outer sheath improves abrasion resistance. Optional PTFE coatings enhance chemical resistance.
- Quality Control: Rigorous testing for tensile strength, elongation, and UV stability ensures compliance with international standards (e.g., CCS, DNV).
Usage Precautions
- Avoid Sharp Edges: Protect the rope from abrasion by sharp objects; use sleeves if necessary.
- Chemical Exposure: Resistant to most chemicals but avoid prolonged contact with oxidizing acids.
- Regular Inspections: Check for wear (≤30% diameter reduction) and replace damaged sections promptly.
- Storage: Keep dry in ventilated areas; avoid direct sunlight or high-temperature environments.
Specifications
| Diameter | 3mm - 300mm |
| Structure | 3-strand, 8-strand, 12-strand, double-braided, or multi-layer configurations |
| Breaking Load | Up to 5,000 tons (depending on diameter) |
| Weight | ~1.5x lighter than steel (e.g., 10mm rope: ~2.5 kg/100m) |
| Temperature Range | -150°C to +70°C |
| Colors | White, black, red, yellow (customizable) |
| Certifications | CCS, DNV, ABS, ISO 9001 |
