1Channel Endress Hauser Transmitter Liquiline CM14 For PH ORP Sensors
Price:
negotiable
MOQ:
1pc
Delivery Time:
12-14weeks
Brand:
Endress+Hauser
Product Description
Endress Hauser 1-channel Transmitter Liquiline CM14 4-wire Transmitter
Product Specifications
| Attribute | Value |
|---|---|
| Approval | Non-hazardous area |
| Sensor Input | Digital, Memosens pH, ORP (glass) |
| Output | 2 x 0/4 to 20 mA |
| Communication | 2 x Relay |
| Country of origin | DE |
Product Overview
The Liquiline CM14 is a basic transmitter offering all essential features for standard measuring points. Designed to fit common cabinet cut-outs, it features easy commissioning through Memosens digital technology. The Memosens hot plug and play concept enables quick installation and configuration of digital pH/ORP, conductivity, or dissolved oxygen sensors.
Key Features
- Compact, easy-to-operate design
- Cost-efficient solution for measurement applications
- Digital Memosens technology for pH/ORP sensors
- Standard panel housing (48x96 mm)
- Suitable for non-hazardous areas
Typical Applications
Ideal for various industries and their utilities including:
- Food & Beverages
- Power & Energy
- Water & Wastewater
Technical Specifications
Measuring principle: Potentiometric
Application: Water, waste water
Characteristic: 4-wire transmitter with two-line display
Design: Panel housing (48x96 mm)
Material: Polycarbonate housing, polyester front membrane
Dimensions: 48 mm x 96 mm x 152 mm (built-in depth)
Ingress protection: Front IP65, NEMA 4X, Body IP20
Input: One-channel transmitter
Certifications: CSA C/US general purpose, UL listed
