PH ORP Conductivity Endress Hauser Liquiline M CM42 1 Channel Transmitter

Price Negotiable

Price: negotiable

MOQ: 1pc

Delivery Time: 12-14weeks

Brand: Endress+Hauser

Product Description

Endress Hauser 1-channel Transmitter Liquiline M CM42 Modular Two-wire Transmitter

Product Attributes

Sensor Input:	Digital, Memosens pH, (glass) ORP
Approval	ATEX II (1)2G Ex ib (ia Ga) IIC T4/T6 G
Certificate	not selected
Output	1x4-20mA, HART
Housing	Plastics (PC)
Cable Entry	Gland M20x1,5

Product Description

The Endress+Hauser Liquiline M CM42 is a robust 1-channel transmitter designed for pH/ORP, conductivity, or oxygen measurement in all process applications. Engineered for demanding environments including hygienic applications, hazardous areas, and functional safety requirements, this transmitter features an intuitive operating concept that simplifies commissioning, handling, and maintenance.

Ideal for multiple industries including:

Chemicals
Food & Beverages
Life Sciences
Power & Energy
Oil & Gas
Primaries & Metal

Key Features

Protocols and interfaces: 0/4...20 mA, HART, PROFIBUS PA, FOUNDATION Fieldbus
International explosion protection approvals: IECEx, ATEX, FM, CSA, TIIS, NEPSI
Measuring principle: Potentiometric pH measurement
Modular two-wire transmitter design for process engineering applications
Developed according to international safety standard IEC 61508
Housing options: Plastic or stainless steel with EPDM sealings
Ingress protection: IP66/67, NEMA 4X

Technical Specifications

Dimensions: Plastic housing: 144 x 144 x 148 mm (5.67 x 5.67 x 5.83 inch) | Stainless Steel: 174 x 174 x 134 mm (6.85 x 6.85 x 5.28 inch)
Temperature sensor: Compatible with Pt100, Pt1000, NTC 30K
Input: One channel transmitter for Memosens and analog (pH, ORP, conductivity)
Output/communication: 1/2 x 4 to 20 mA, HART, Profibus PA, FF (additional second output possible)
