Fusion Bonded Epoxy Bolted Water Storage Tanks Food Grade For Drinking Water Beverage Storage
The Fusion Bonded Epoxy Bolted Tank (FBE Bolted Tank) is a specialized storage solution offering numerous advantages. Featuring a regular geometric design, it's available in various sizes to accommodate diverse storage requirements. Its structure comprises specially treated metal sheets interconnected by bolts, creating a robust and stable configuration.
The fusion-bonded epoxy coating provides exceptional corrosion resistance, effectively withstanding acids, alkalis, salts, and other corrosive substances. This ensures long-term safe usage even in harsh environments. The bolted connection method guarantees tank seal integrity while simplifying installation, disassembly, and maintenance processes.
- Exceptional corrosion resistance: Fusion-bonded epoxy coating provides superior protection against chemical degradation
- Simplified installation: Bolted connection method enables convenient on-site assembly and disassembly
- Enhanced structural integrity: Optimized design effectively endures specific pressure and weight loads
- Extended service life: Remarkable corrosion resistance and structural integrity significantly prolong product lifespan
| Coating color | Dark blue, dark green, white, and customized |
| Standard steel plate size | Effective size 2400mm x 1200mm |
| Steel plates thickness | 3mm - 18mm (depends on diameter & height) |
| Coating thickness | 5~10 mils / 125~250 microns |
| PH Range | 3~12 |
| Impact Resistance | 160 in-lbs direct & reverse impact |
| Elastic | Same as steel sheet (~500KN/mm) |
| Hardness | 2.0H |
| Service life | >20 years |
| Holiday test | ≥1100 V |
| Permeability | Gas and liquid impermeable |
- Petroleum and Chemical Industry: Storage of chemicals, petroleum products, and liquid chemicals
- Food and Beverage Industry: Storage of edible oils, alcohol, and other raw materials
- Water Treatment: Storage of clean water, wastewater, and processing liquids
- Energy Industry: Storage of fuel oil and liquefied natural gas (LNG)
- Agricultural Sector: Farm digestion tanks for waste processing and biogas production
- Industrial Water Treatment: Filtration tanks for water purification
- Fire Protection: Firewater reservoirs
- Agricultural Production: Storage of fertilizers and agricultural chemicals
- Environmental Management: Stormwater collection and industrial wastewater treatment
We provide installation tools and send 1-2 engineers to guide installation. Alternatively, we can provide a complete installation team. Our tanks offer 30 years' service life with minimal maintenance required. All tanks come with a 2-year quality warranty after installation completion.
