Dongfeng 4 Tons Road Recue Towing Vehicle 6tons Wrecker Recovery Truck Body
1. Purpose of 6ton flatbed tow truc: wrecker/recovery truck/towing truck is used for towing broken cars,vehicle on road.With increasing ownership of private cars,wreckers are now widly used by government organization or towing company.
2. Optional brand of 6ton flatbed tow truc:howo,Dongfeng,JAC,JMC,Foton,Shacman...
3. Spare parts of 6ton flatbed tow truc: Italy brand multi-way valve and balance valve; Gernamy Roxroth technology hydraulic cylinder and joint; imported sealing element; strengthed checked plate
4. Capacity range of 6ton flatbed tow truc:3ton, 4ton, 5ton, 6ton, 8ton, 12ton, 16ton, 20ton, 25ton, 31ton, 40ton, 50ton
5. The customers can choose to install the crane.
| General Technical Parameters | |||
| Overall Dimension | 7450x2350x2440 (mm) | ||
| Gross Vehicle Weight | 8275kg | ||
| Curb Weight | 5110kg | ||
| Chassis Specification | |||
|
Chassis Parameters |
Chassis Brand | dongfeng | |
| Cabin | Row and half, left Hand Driving or right hand drive | ||
|
Engine |
Model | CY4102-C3C, 4 Cylinders | |
| Power | 88KW/120HP | ||
| Emission Standard | EURO III | ||
| Displacement | 3856mL | ||
| Fuel Type | Diesel | ||
| Gearbox | 5 Forward & 1 Reverse Gear | ||
| Front and Rear Axle Load | 3.3T/4.9T | ||
| Wheel Base | 3800(mm) | ||
| Overhang( Front/Rear) | 1015/2450(mm) | ||
| Angle(Approach/departure) | 24/9(°) | ||
| Brake System | Air Brake | ||
| Steering Gear | Power Assistant | ||
| Tire | 7.50R16, 6 Pieces with 1 Spare Tire | ||
| Maximum Speed | 110(km/h) | ||
| Superstructure | |||
|
Winch |
Quantity | 1pc | |
| Winch Rating Pulling Capacity | 4000 (kg) | ||
| Length of Steel Cable | 21 (m) | ||
|
Remarks |
1. Equiped with One Set of Auxiliary Wheels 2. Fork 1 set 3. Yellow Warning Lamp 1pc 4. Double Side Hydraulic Operation 5. Bangdage 4 sets 6. chain hook |
||
