Sinotruck HOWO 20ton Mining Construction Tipper Truck For Mining Transportation Truck
Price:
15000-35000 per unit
MOQ:
1
Delivery Time:
35 Days
Brand:
CLW
Product Description
Product description
China Sinotruck HOWO 20ton Mining Construction Tipper Truck for Mining Transportation Truck
Product description:
- Dump truck brand: SINOTRUK HOWO, CAMC, SHACMAN, JAC, NORTH-BENZ, FOTON, etc.
- Tipping Model of dump truck: Front-tipping, Middle-tipping.
- Hydraulic oil cylinder brand of dump truck: International brand HYVA or Chinese famous brand.
- High tensile steel for dumper materia of dump truck: 4mm, 6mm, 8mm,10mm or as per customer's request.
- Used in Construction or Mineral site for Transportation of mineral, stone, sand, garbage and so on.
Specification of dump truck:
| Truck Specifications | ||||
| Chassis Brand | SINOTRUK HOWO | |||
| Drive model | 8x4 | |||
| Loading capacity | 40-50tons | |||
| Overal Dimension | 10145x2550x3450mm | |||
| Carriage Internal Dimension | 5600x2300x1500mm | |||
| Dump Van Volume | 20m3 ( 16-21m3 for option ) | |||
| Steel Thickness of Carriage | Bottom 10mm, Side 8mm (As Per Client's Request) | |||
| Dumper Material | Q345B | |||
| Hydraulic Lift of Carriage | Front Lift (HYVA cylinder or middle lift for option ) | |||
| Model | SINOTRUK HW76 Lengthen cab | ||
| single bunk, new type seat, adjustable steering wheel, EURO new type heating & ventilating system, German VDO instruments, safety belts, exterior sun visor, stereo radio/cassette recorder, left driving, air conditioner | ||||
| Model | D10.38-30 | ||
| Manufacturing Company | SINOTRUK | |||
| Maximum output | 380HP | |||
| Emission standard | Euro III | |||
| Number of cylinder | 6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection | |||
| Transmission | SINOTRUK HW19710 transmission ,10 forward and 2 reverse | |||
| Clutch | SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance. | |||
Steering | ZF8118 Steering Gear Box, hydraulic steering with power assistance. (Left hand driving), ( ZF8098 RHD right hand drive for option ) | |||
| Wheel Base | 1800+3750+1350mm | |||
| Wheels&Tires | Rims:10 hole-steel ;Tyres:12.00R20 radial tyre with 1 Spare tire. ( tubeless for option ) | |||
| Front Axle | SINOTRUK HF9 Front Axle,new 9-ton front axles of equipped with drum brakes. | |||
| SINOTRUK HC16 Heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles, enforced STR axle,ratio:5.73;The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers. | |||
| Service brake | Dual circuit compressed air brake | ||
| Parking brake(emergency brake) | spring energy,compressed air operating on rear wheels | |||
| Oil Tank | Square type-300L Aluminum alloy fuel tank | |||
| Operating voltage | 24V,negative grounded | ||
| Starter | 24V,7.5 Kw | |||
| Alternator | 3-phase,28V,1500 W | |||
| Batteries | 2x12 V,165 Ah | |||
| Lights | horn,headlamps,fog lights,brake lights,indicators and reverse light. | |||
| Maximum driving speed | 75 km/h | ||
| Fuel consumption | 35 L/100km | |||
| Revolving Light on roof of cab | |||
| RHD right hand drive | ||||
| Upper body | bucket shape body for heavy good,big size stones etc | |||
| U shape body bulk cargo , ore and other goods | ||||
| Boat type body bulk, muck, geotechnical class | ||||
| Tubeless tires | 12R22.5, 315/80R22.5 etc | |||
| Brake water spray | ||||
| ABS, EVB engine brake | ||||
