Sinotruk Howo 6x4 Dump Truck 336 371 10 Wheeler 40 Ton Tipper Truck
Price:
15000-35000 per unit
MOQ:
1
Delivery Time:
30-40days
Brand:
CLW
Product Description
Sinotruk Howo Dumper Truck 6x4 336 371 10 Wheeler 40Ton Tipper Truck Dump Truck with low price
Product Description
- Dump truck brand:SINOTRUK HOWO,CAMC,SHACMAN,JAC,NORTH-BENZ,FOTON...
- Tipping Model:Front-tipping,middle tipping dump truck,HYVA or Chinese brand hydraulic oil cylinder brand
- High tensile steel for dumper materia,4mm,6mm,8mm, 10mm oer as per client's request and purpose.
- Used in construction site for transportation of mineral,stone,sand and so on.
Specification
| Condition | New condition/Left hand drive/6X4 drive model/SINOTRUK HOWO | |||||
| | Curb weight(Including upper weight) | 12,110 | |||
| Loading weight | 30,000 | |||||
| Gross weight | 41,000 | |||||
| Front axle loading capacity | 9,000 | |||||
| Rear axle loading capacity | 16,000x2 | |||||
| Wheelbase | 3800+1350 | ||||
| Overall Dimension | 8300*2496*3450 | |||||
| Approach angle(o) | 19 | |||||
| Departure angle(o) | 17 | |||||
| Front axle | HR9; Steering with double T-cross section | |||||
| Rear axle | AC16; Pressed axle housing, central single reduction and differential locks between axles; Ratio: 4.11 | |||||
| Clutch | Single- plate dry diaphragm spring clutch | |||||
| Brakes | Air brakes | |||||
| Steering | ZF8118 | |||||
| Wheel & Types | Rims | 8.5-20,10 hole-steel | ||||
| Types | 12R22.5 with one spear tire, 11 pcs in total | |||||
| Transmission | Model HW19710, 10 forward and 2 reverse, with PTO | |||||
| Cabin | HW70/HW76 | |||||
| Make | SINOTRUK | ||||
| Model | WD615.47 | |||||
| Description | 4 stroke direct injection diesel engine 6 cylinder in-line with water cooling, turbo-charging & intercooling | |||||
| Displacement(ml) | 9726 ml | |||||
| Power | 371HP | |||||
| Upper | ||||||
| Type | U-type | ||||
| Size(mm) | 16CBM; 5400*2300*1300 mm | |||||
| Max. Loading weight(kg) | 30tons-35tons | |||||
| Button Thickness(mm) | 6.0 mm | |||||
| Side plate Thickness(mm) | 4.0 mm | |||||
| Material | Hardox 450/NM 450 | |||||
