ISUZU 120HP Box Truck Van Cargo Truck Light Duty Mini Lorry Truck
ISUZU 120HP Light Duty Cargo Box Truck Van Lorry Mini Truck
Description:
1. Strong power, super load capacity. We can provide trucks with a load capacity of up to 40 tons.
2. Warranty: One year for the engine, gear box, and axles.
3. Rear Hydraulic Lifting Platform can carry 1500 kg.
4. Technical supporting and modification according to customers' requirements are available.
120HP CRAGO TRUCK Parameters
| Parameters of chassis | |
|---|---|
|
Cabin |
Q28 Flat top cab/no berth/with thermal insulation cab /seats 3 people/with reversing video/center control touch-sensitive electronic screen/air conditioning/metal bumper/electric doors and Windows/center control lock / independent diesel heating/With low temperature start function |
| Driving Type | Manual left hand drive |
| Drive Wheel | 4x2 |
| GVW | 8000(kg) |
| Curb weight | 3000(kg) |
| Loading capacity | 5000(kg) |
| Overall dimensions | 6000*2200*2700 (mm) |
| Box dimensions | 4200*2200*2100(mm) |
| Number of axles | 2 |
| Wheelbase | 3300(mm) |
| Front axle | 1.3T |
| Rear axle | 3.5T |
| Frame | 188*750,6(mm) |
| Suspension | Multi leaf spring suspension front and rear |
| Wheels and tires | 7.00R16,with one spare tire |
| Brake | Air brake with ABS |
| Air reservoir | Aluminium alloy |
| Battery | Camel battery , 12V |
| Fuel tank | Aluminium alloy tank |
| Pipeline | Low temperature oil and gas pipeline |
| Parameters of engine | |
| Model | ISUZU - 4KH1CN6LB |
| Function | With low temperature start function |
| Fuel | Diesel |
| Emission standard | Euro 5(Shield exhaust treatment system) |
| Transmission | Manual WLY, 6GS46 ,6 forward |
| Number of cylinder | 4 |
| Rated speed | 3200(r/min) |
| Max.Torque | 278N.m/1800~2200r/pm |
| Power | 88/120(kw/hp) |
| Displacement | 2.771(L) |
| Cargo box parameter | |
| Box dimension | 4200x2100x2100(mm) |
| The thickness of the side | 1mm |
| The thickness of the bottom | 2mm |
| Box material | Corrugated iron sheet |
| Paint | Electrophoretic spraying process |
Products Catalog:
1. LPG Tank Truck Trailer/ Fuel Tanker Truck/ LPG station
2. Water truck / Water Tank Truck / Water Sprinkler Truck/Water Tanker
3. Truck with crane / Truck mounted crane
4. Dump Truck / Tipper Truck/Side Tipper/End Tipper
5. Fire Fighting Truck / Fire Truck / Fire Vehicle
6. Concrete Mixer Truck
7. Van truck /Refrigerated truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck
12. Tractor
13. High Pressure Cleaning Truck
14. Sweeper Truck
15. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
