SHACMAN 10tons Water Mist Disinfectant Sprayer Tanker Vehicle Disinfectant Truck Watering Sprinkler Tanker Truck
Price:
15000-35000 per unit
MOQ:
1
Delivery Time:
40days
Brand:
CLW
Product Description
SHACMAN 10tons water mist disinfectant sprayer tanker vehicle disinfectant truck watering sprinkler tank truck
Product Description
- Optional chassis brand of city disfection truck: Dongfeng, Sinotruk, FOTON/Forland, Faw, Shacman,
- Material of city disfection truck :High Tension Steel Q235,stainless steel 304 for option.
- Sprinking Width of portable water truck :>14M
- Rear working platform with water cannon range of portable water truck :28M
- Water Tank: square or round tank for option,square tank,high-quality Q235 carbon steel treated for anti-corrosion and anti-rust
- large flow water pump as standard, 50-100 meters fog Gun machine for option;
- TDM-M06 60 meters, generator power 50KW, fan power 22KW, stainless steel multistage centrifugal pump power 11KW, 100 meters wireless remote control operation.
Application of city disinfection truck :
- Used for for municipal sanitation projects such as urban street smog treatment,city disinfection and sterilization of public places,garden greening,pesticide/mosquito liquid spraying.
- Used in metallurgical industry, mining industry, chemical industry, construction site, house demolition and reconstruction site, leveling site and other fields generating dust during the production, construction and transfer process.
- Used in open-air coal storage, coke, sand, stone and other industrial and mining enterprises and other bulk material handling yards.
- The front flushing, rear sprinkling and rear operation water cannon are suitable for environmental dust reduction, road cleaning and billboard cleaning of urban roads. The left and right greening irrigation devices can be used for irrigation operations of highway green belts.
Spefications:
| Chassis parameters | |||
| Condition | New condition/Left hand drive/4x2 | ||
|
Main details |
Brand | Shacaman H3000 | |
| Whole truck curb weight(kg) Chassis with garbage container |
10220 kg | ||
| Wheelbase(mm) | 4500 and 4700 mm | ||
| Dimensions(mm) | 9200*2500*3750 mm | ||
| Front/Rear Axle loading(kg) | 4500/10000kg | ||
| Wheel track (front/rear) (mm) | 1923/1865 mm | ||
| Front/Rear overhang(mm) | 1230/2900 mm | ||
| Approach/Departure angle(°) | 19/9 ° | ||
| Max. driving speed(km/h) | 90 | ||
| Clutch | Dry single plate with diaphragm spring, Φ250, vacuum assistance |
||
|
Brakes |
Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake |
||
| Steering Gear | Power steering, hydraulic steering with power assistance | ||
| Suspension | Front/rear leaf spring | ||
|
Tire |
Quantity | 6 pcs with one spare tire | |
| Specifications | 10.00R20 tire | ||
| Transmission | Manual type, 2 Forwards and 2 reverses | ||
| Cabin | It can accommodate three people. With Air Conditioner | ||
|
Engine |
Brand | Shacaman | |
| Model | WP6.180E50 | ||
| Type | Turbocharged | ||
| Max power/Horsepower)KW/HP) | 132KW/180HP | ||
| Max torque(N·m/rpm) | 700N.m/1200-1700rpm | ||
| Displacement (cc) | 5900 cc | ||
| Fuel type | Diesel | ||
| Emission standard | Euro 3 | ||
| Super Structure parameters | |||||
|
Water tanker |
Type | Square | |||
| Volume(cbm/liters) | 10cbm | ||||
| Tank material | Q235 carbon steel | ||||
|
Water pump |
Brand | China famous brand WeiLong | |||
| Model | 50/110 | ||||
|
Disinfection Machine |
Brand | China famous brand | |||
| Model | 60A | ||||
| Overall size(mm) | 2000*1600*1760 mm | ||||
|
Deputy engine |
Brand | China famous brand | |||
| Power(KW) | 50 KW | ||||
| Water pump | Brand | China famous brand | |||
| Pressure(Mpa) | 1.5-3.5 Mpa | ||||
| Maximum range(m) | 55-60m | ||||
| Flow rate(m3/H)) | 6 m3/H | ||||
| Fog drop particles(μm) | 50-150 μm | ||||
| pitching angle(°) | -5 ~ 50 ° | ||||
| rotating angle(°) | 320° | ||||
| Fog spray nozzles quantity(pcs) | 60 pcs | ||||
|
Low pressure water spray system |
Water cannon range(m) | ≥28 m | |||
| Front flushing width (m) | ≥14 m | ||||
| Rear spraying width(m) | ≥14 m | ||||
| Side spraying width(m) | ≥14 m | ||||
|
Remarks |
Painting as client's request Customized LOGO design |
||||
