Dongfeng 10 Wheelers Cement Mixer Truck Concrete Mixer Mining Construction equipment Mixing Truck Cement Truck
Price:
15000-35000 per unit
MOQ:
1
Delivery Time:
35days
Brand:
CLW
Product Description
Dongfeng 10 wheelers cement mixer truck concrete mixer mining construction equipment mixing truck cement truck
Product Description
- Purpose: For long distance or short distance transporting concrete in construction site.
- Main parts: Hydraulic pump, hydraulic motor, reducer and radiator etc.
- Chassis: Dongfeng, SHACMAN or SINOTRUK 4x2 chassis for optional.
Specifications:
| Cabin | Driving type 4x2, LHD | |
|---|---|---|
Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 8100*2500*3030 |
| Wheel base (mm) | 4350+1300 | |
| Wheel track (front/rear) (mm) | 1500/3150 | |
| Approach/Departure angle(°) | 32/14 | |
Weight in KGS | Tare weight | 14100 |
| payload | 10770 | |
| Front axles loading capacity | 4500 | |
| Rear axles loading capacity | 11500 | |
| Max. driving speed(km/h) | 85 | |
Engine | Brand | YUCHAI |
| Type | 4-stroke direct injection , 4-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
| Horse Power(HP) | 280 | |
| Emission standard | Euro II | |
| Gearbox | 8 forwards & 2 reverse | |
| Steering | Left hand drive | |
| Tire | 10 pcs with one spare, 12.00-R0 | |
| Upper frame structure | ||
Mixer Drum | Mixer Capacity | 10 cubic meters |
| Drum thickness | 6mm | |
| Blade thickness | 4mm | |
| Tanker Material: | Q345 Carbon Steel | |
| Filling Rate(%) | 59 | |
| Input Speed (m3/min) | ≥2.8 | |
| Output Speed (m3/min) | ≥1.2 | |
| Surplus Ratio | ≤0.5 | |
| Tanker Rotate Speed(rpm) | 0~17 | |
Drum Drive System | Hydraulic Pump | Italy Brand: PMP |
| Hydraulic Motor | Italy Brand: PMP | |
| Speed Reducer | Germany Brand: ZF | |
| Radiator | KAITONG | |
| Water Tank Volume(L) | 400 | |
