Sinotruk HOWO 6X4 18cbm Sewer Vacuum Truck , Sewage Cleaning Truck 160HP
SINOTRUK Howo 6x4 18CBM Sewer Vacuum Trucks Sewage Suction Cleaning Tanker Truck
Description
Sewer Vacuum Truck(also called vacuum truck,vacuum tanker,sucker truck,sewer sucker,hydro-vac,vac-trucks,exhauster truck,sewer vacuum truck,septic suction truck,sewage vacuum truck,sewer cleaning truck,sewage tanker,cessipit emptier,gully emptier,drainage suction truck,vacuum truck,sewage truck,waste vacuum truck,drainage treatment truck) is one of the new sanitation type vehicle to collect,clean and transport sludge, sewage to avoid secondary pollution. Sewer Vacuum Truck is with advantage of self-suction from discharge, fast working speed, large capacity, convenient transportation suitable for the collection and transport of feces, mud, crude oil and other liquid materials.
Also with advantage of large suction force and long suction distance, especially suitable for the suction, delivery and discharge of silt in the sewer, especially for the suction of the sewer mud, stones, bricks and other large objects.
Feature
- Sewer Vacuum Truck material optional for carbon steel or stainless steel 304;
- Tanker thickness 6~8mm,endplate thickness 8mm and baffle 5mm;
- Sewage suction pump is optional for chinese brand single weilong pump,water ring suction pump,Italy brand BP,Jurop,Keiser Moro imported brand;
- Suction speed less than 10min and and discharge speed less than 8 min;
- horizontal suction distance: within 80 meters;
- Vertical suction depth:within 9 meters;
- Large horsepower 290hp,336hp or 371hp howo truck chassis;
Specification of Sewer Vacuum Truck
| Product Information | ||
| Product | Sewage suction truck | |
| Brand Name | SINOTRUK-HOWO | |
| Chassis Model | ZZ1257N4647 | |
| Place of Origin | Suizhou, China | |
| Color | Any color will be available | |
| Product Specifications | ||
| Engine Power | 249kw/336hp | |
| Overall dimension(L*W*H) | 10350*2496*3800 | |
| Effective volume | 15m3/16m3/18m3 | |
| Wheelbase | 4600+1350mm | |
| Front overhang | 1500mm | |
| Rear overhang | 2900mm | |
| Tread | 2022/1830mm | |
| Max speed | 90/102km/h | |
| Vehicle gross weight | 25000kg | |
| Front axle | HF7 | |
| Rear axle | ST16 | |
| Transmission | 10 speeds forward and 2 reverse | |
| Tire | 295/80R22.5, 10+ 1 spare | |
| Cabin | HW76, one sleeper with AC | |
| Diameter of suction tube | Φ100mm | |
| Suction depth | 6m | |
| Vacuum pump | Jurop pump/Mono Keiser/BP/Chinese pump SK-12 | |
| Absorb pipe | 4" 6meter black pipe | |
| Material | Carbon steel Q235-B |
| Thickness | Shell cover:8mm, Tank body:6mm | |
| sewage tank | 16000L | |
