28m-32m Telescopic Boom Hydraulic Man Lift Truck For Aerial Work
28-32m Telescopic Boom Hydraulic Manlift Truck For Aerial Work
- Electronical controlled Lifting Arm with Doulbe Side Balance Vavle.
- Four Hydraulic Cylinders Control Leg to ensure the Truck Balance.
- 360 degree Rotation Arms.
- Arm and H leg Automatic Locking System to secure safety handling
| Chassis brand | SINOTRUK HOWO | Chassis model | ZZ1047 |
| Lift height customization | 18 meter | Total mass (kg) | 7305 |
| Engine horsepower | 120hp | Rated load mass (Kg) | 7110 |
| Engine name | YN4102QBZL | Emission Standards | Euro 3 |
| Dimensions (MM) | 7300×2000×3100 | Fuel type | Diesel |
| Number of tires | 6 | Tire specifications | 7.50R16 |
| Wheelbase (MM) | 3815 | Maximum speed (km/h) | 95 |
| Front track | 1506 | Rear track | 1530 |
|
Dedicated configuration |
1. Maximum working height: 18 meters, maximum working range: 7.5 meters |
||
|
2. Adopting the international leading Jiangling high-end chassis and installing three-section folding arm hydraulic lifting special device |
|||
|
3. Environmental protection items to the national motor vehicle fifth stage emission standards (country V) |
|||
|
4. Adopting domestic and imported reversing valve and hydraulic cylinder, the commutation is stable, the operation is flexible and convenient, the hydraulic system realizes the interlocking of the upper and lower vehicles, the overload protection, and the cylinder is safely locked. |
|||
|
5. Turntable, work bucket double station operation |
|||
|
6. The boom has a compact structure, good maneuverability and large working range. |
|||
|
7. The legs and the working arm are interlocked, safe and reliable, preventing misoperation |
|||
|
8. H-type legs, large span, good stability, the legs can be independently telescopic, and can be linked, equipped with a leg flashing light, used for the leg profile during operation, emitting a light alarm signal |
|||
|
9. Waterproof switch has limit function, dangerous working condition alarm, superior safety performance |
|||
|
10. Optional 1 ton hook (hook telescopic 800-1000mm), hook maximum lifting mass 500kg |
|||
|
11. Optional automatic protection system to prevent misoperation |
|||
|
12. Optional emergency power source, ignition and flameout device |
|||
|
13. Optional electronic control system for electro-hydraulic proportional speed control, stepless speed regulation, smooth operation / electronic control system optional ground wireless remote control operating system |
|||
|
14. Optional 10, 11, 13, 14, 16 , 18, 20, 22, 24meters series of aerial work. |
|||
