Drop Impact Testing Machine Ik01-10 Pendulum Steel Hammer Aluminum Test Bench
IK Mechanical Impact Test Apparatus IK01 - IK10 Pendulum Steel Hammer Aluminum Test Bench
This testing device conforms to IEC62262 and is used for mechanical strength testing of sheet metal components including substation arks and metalloid electric energy metering cubicles. The mounting bracket and impact angle are adjustable, designed for energy impact testing exceeding 2J.
- Electrical & Electronics: Lighting fixtures, switches, instrument housings
- Security & Telecommunications: Surveillance cameras, outdoor communication boxes
- Automotive: External components like headlights and control panels
- Public Infrastructure: Traffic lights, outdoor signage, smart meters
- Industrial Equipment: Protective covers, control cabinets in impact-prone environments
| Energy (J) | ≤1 ±10% | 2 ±5% | 5 ±5% | 10 ±5% | 20 ±5% | 50 ±5% |
|---|---|---|---|---|---|---|
| Equivalent Mass ±2% (kg) | 0.25 (0.2) | 0.5 | 1.7 | 5 | 5 | 10 |
| Material | nylon | steel | ||||
| R (mm) | 10 | 25 | 25 | 50 | 50 | 50 |
| D (mm) | 18.5 (20) | 35 | 60 | 80 | 100 | 125 |
| f (mm) | 6.2 (10) | 7 | 10 | 20 | 20 | 25 |
| r (mm) | - | - | 6 | - | 10 | 17 |
| Energy (J) | 0.14 | 0.2 | (0.3) | 0.35 | (0.4) | 0.5 | 0.7 | 1 | 2 | 5 | 10 | 20 | 50 | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Equivalent Mass (kg) | 0.25 | (0.2) | 0.25 | (0.2) | 0.25 | (0.2) | (0.2) | 0.25 | 0.25 | 0.25 | 0.5 | 1.7 | 5 | 5 | 10 |
| Drop Height ±1% (mm) | 56 | (100) | 80 | (150) | 140 | (200) | (250) | 200 | 280 | 400 | 400 | 300 | 200 | 400 | 500 |
| IK Code | IK00 | IK01 | IK02 | IK03 | IK04 | IK05 | IK06 | IK07 | IK08 | IK09 | IK10 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Impact Energy (J) | a | 0.14 | 0.2 | 0.35 | 0.5 | 0.7 | 1 | 2 | 5 | 10 | 20 |
- Customer Inquiry: Technical requirement discussion and product recommendation with competitive pricing
- Customization: Detailed drawings and reference photos for specification confirmation
- Production & Delivery: Manufacturing with progress updates, calibration services, and timely shipping
- Installation & Support: On-site installation and comprehensive after-sales service
Yes, we are a professional manufacturer of Environmental Chambers, Leather shoe testing equipment, and Plastic Rubber testing Equipment. Every machine includes a 12-month warranty after shipment, with extended coverage for sea transportation. For technical support, contact us via email or phone for problem resolution within 24-48 hours.
Standard machines with stock: 3-7 working days. Custom orders: 15-20 working days after payment. Urgent requests receive special priority scheduling.
Yes, we offer both standard and customized machines according to your specifications, including OEM and ODM services with your logo.
We provide English operation manuals and videos. Most machines are shipped fully assembled - simply connect power and begin operation. On-site installation assistance is available when necessary.
