Ultra Thin Stainless Steel Wire Cloth , Metal Mesh Fabric For RFI EMI Shielding
Ultra thin stainless steel woven wire mesh cloth for RFI EMI shielding
stainless Steel Ultra-thin Wire Mesh is a kind of woven stainless steel wire mesh with uniform opening and good firmness. The uses of carefully selected special stainless alloy materials and the most advanced weaving technology adopted ensure the very compact weaving structure is achieved and the thickness of the wire mesh is within the allowed tolerance range. Hence the precision of the wire mesh is further enhanced for high precision printing requirements.
Ultra-thin stainless steel wire cloth is used typically when heat and corrosion resistance is required, and frequently utilized in applications requiring shielding of electromagnetic interference and radio frequency interference.
Material: SS304, 304HC, 304L, 316, 316L.
Weave: Plain weave.
Application: Super-Thin Stainless Steel Wire Meshes are widely used as shielding materials.
Specification:
| Mesh / Inch | Wire Dia | Mesh / Inch | Wire Dia |
|---|---|---|---|
| mm | mm | ||
| 24 | 0.19 | 100/50 | 0.056 |
| 30 | 0.165 | 105/64 | 0.063 |
| 38 | 0.114 | 115/55 | 0.08 |
| 58 | 0.114 | 120/76 | 0.056 |
| 70 | 0.076 | 130/65 | 0.043 |
| 84 | 0.063 | 140/65 | 0.063 |
| 100 | 0.056 | 160/80 | 0.036 |
| 130 | 0.043 | 170/105 | 0.043 |
| 150 | 0.034 | 180/85 | 0.045 |
| 160 | 0.036 | 180/85 | 0.05 |
| 180 | 0.03 | 180/90 | 0.03 |
| 200 | 0.028 | 210/100 | 0.046 |
| 230 | 0.028 | 220/110 | 0.028 |
| 270 | 0.036 | 235/115 | 0.043 |
| 300 | 0.03 | 260/130 | 0.04 |
| 64/38 | 0.1 | 300/150 | 0.028 |
| 76/45 | 0.086 | 310/160 | 0.036 |
| 84/42 | 0.063 | 325/150 | 0.036 |
| 90/43 | 0.09 | 325/184 | 0.028 |
| 90/50 | 0.076 | 400/205 | 0.03 |
