Milled Plastic Mold Steel Plate P20 / 3Cr2Mo Thickness 10 - 350mm MTC Assured
1.2311 / P20 / 3Cr2Mo / PDS-3 Plastic Mold Steel Plate for Pre-hardened Injection Mold
For high demand large-sized or medium-sized precision plastic mould and alloy parts.
1. Equivalnet grades:
| GB | DIN | AISI | JIS |
| 3CR2Mo | 1.2311 | P20 | PDS-3 |
2. Chemical Composition(%) :
| C | Si | Mn | Cr | Mo | S | P | Ni |
| 0.28-0.40 | 0.20-0.80 | 0.60-1.00 | 1.40-2.00 | 0.30-0.55 | ≤0.003 | ≤0.030 | 0.05-0.10 |
3. Available size(mm):
| Plate | Thickness (mm) | Width (mm) | Length (mm) |
| 10-350 | 2000-2200 | 4000-12000 | |
| Block | Thickness (mm) | Width (mm) | Length (mm) |
| 200-1000 | 800-1600 | 2000-6000 | |
| Round Bar | Diameter (mm) | Length (mm) | |
| 10-350 | 4000-12000 | ||
4. Hardness: 28-32HRC
a, Good hardness uniformity and polishing property,good machining properties.
b, Good integral machanical performance under high temperature.
c, Good heat-resistance and fatigue-resistance.
d, Pre-hardened to HRC28-32, can be directly used for mould processing, shorten the construction period.
e, High putity and homogeneous structure of China's biggest ESR production base for its strict requirement in the whole process of exploitation, smelting, vacuum degassing, ESR, forging,
6. Applications:
Used for various lager-sized or medium-size precision plastic mould and alloy parts.
a, Ideally suited for the production of plastic moulds;
b, Die holders, zinc die casting dies, backers, bolsters and injection moulds;
c, Shafts, rails and wear strips;
About GUANGZHOU CHANGFENG STEEL Co., Ltd
Q: Are you a manufacturer or merely a trader?
A: We are group of companies and owned manufacturer bases and trading company. We specialized in plastic mould steel, hot work mould steel, cold work mould steel, alloy steel for mechanical, high speed steel, etc. All material are with high quality and competitive price.
Q: How do you guarantee the quality of your product?
A: Firstly, we can provide the certificates from the third party, such as SGS, CE, ISO if you need. Secondly, we have a complete set of inspection system and every process is checked by QC. Quality is the lifeline of enterprise survival.
Q: Delivery time?
A: We have ready stock for most of material grades in our warehouse. The delivery time is within 20 working days. If the material don't have stock, the lead time is about 30-50days (depend on the quantity) after receiving your prepayment or firm order.
Q: What is the payment term?
A: T/T or L/C or Trade Assurance.
Q: Can we visit your company and factory?
A: Yes, warmly welcome! We can book the hotel for you before you come to China and arrange our driver to our airport to pick you up when you come.
