ASME B16.9 Carbon Steel Pipe Fittings SCH40 Carbon Steel Reducing Tee
ASME B16.9 Carbon Steel Pipe Fittings SCH40 Carbon reducing tee
Description of SCH40 Carbon reducing tee
SCH40 Carbon reducing tee is a widely used pipe, which is mostly used to transport liquid or other pipelines, such as oil, gas, natural gas and so on. Some processing areas will also use SCH40 Carbon reducing tee, such as bicycle frame, automobile transmission shaft and so on.
Technical data sheet of SCH40 Carbon reducing tee
ASME B16.9 Carbon Steel Pipe Fittings SCH40 Carbon reducing tee technical data sheet as below:
| Nominal diameter |
Outside diameter | Center to End | ||
| D | C | M | ||
| A Series | B Series | |||
| 15 | 21.3 | 18 | 25 | |
| 20 | 26.9 | 25 | 29 | |
| 25 | 33.7 | 32 | 38 | |
| 32 | 42.4 | 38 | 48 | |
| 40 | 48.3 | 45 | 57 | |
| 50 | 60.3 | 57 | 64 | |
| 65 | 76.1(73) | 76 | 76 | |
| 80 | 88.9 | 89 | 86 | |
| 90 | 101.6 | - | 95 | |
| 100 | 114.3 | 108 | 105 | |
Specification of SCH40 Carbon reducing tee
Usage: Convey Water Gas Oil
Standard:GB/T10002.2-2003
Size:3/4'',1/8' ~ 6'
Characteristic of SCH40 Carbon reducing tee
SCH40 Carbon reducing tee is a simple way to write 20 × steel, which is a kind of raw material in steel. It is often used to make reducing tee. The uniform carbon content, silicon content, manganese content, sulfur content, phosphorus content, chromium content and nickel content in the steel are 0.17-0.23%, 0.17-0.37%, 0.35-0.65%, 0.035%, 0.035%, 0.20% and 0.30%, respectively.
| Porduct Name | SCH40 Carbon reducing tee |
| Size | 1/2"-24" seamless,26"-110"welded |
| Standard | ANSI B16.9.MSS SP 43, DIN2615, EN10253, GOST17376, JIS B2313, MSS SP 75, etc. |
| Wall thickness | STD, XS, XXS, SCH20,SCH30,SCH40, SCH60, SCH80, SCH160, XXS and etc. |
| Type | Equal/Straight tee,reduced tee,Y tee,jateral tee,Barred tee,split tee,tee cross |
| End | bevel end/BE/buttweld |
| Surface | nature color; varnished, black painting, anti-rust oil etc. |
Package of SCH40 Carbon reducing tee
a. Plastic bubble bag package b.Wove bag package c.Pallet d. Customized.
Delivery time of SCH40 Carbon reducing tee
Our Steel flat factory have high ability for production, the delivery time is 30 days for small quantity, or if you are hurry for that, we can arrange and meet your shipping date.
