ASME B16.5 Class 150 To 2500 Lbs Carbon Steel Flanges IF Integral Flange
ASME B16.5 Class 150 to 2500 lbs IF Carbon steel integral flange
Description
Carbon steel integral flange is butt welded with a long neck. In terms of appearance, the integral flange pipe end is thicker than the butt welded flange pipe end, and the internal diameter of the integral flange is the same as the nominal diameter except for PN1.6MPa and dn450.
Specification
OD:1/2"-24"
Size:DN15-DN2000
Pressure:Class150/300/600
Standard:ANSI, DIN, GB, ISO,ASME
Technical data shee
ASME B16.5 Class 150 to 2500 lbs IF Carbon steel integral flange technical data sheet as below:
| Nominal diameter | size(mm) | ||||
| diameter D | D1 | Bolt hole diameter | D2 | f | |
| 10 | 90 | 60 | 14 | 41 | 2 |
| 15 | 95 | 65 | 14 | 46 | 2 |
| 20 | 105 | 75 | 16 | 56 | 2 |
| 25 | 115 | 85 | 16 | 65 | 3 |
| 32 | 140 | 100 | 18 | 76 | 3 |
| 40 | 150 | 110 | 18 | 84 | 3 |
| 50 | 165 | 125 | 20 | 99 | 3 |
| 65 | 185 | 145 | 20 | 118 | 3 |
| 80 | 200 | 160 | 22 | 132 | 3 |
Characteristic
Carbon steel integral flange has high neck height and relatively thick wall thickness. In terms of application, the integral flange is the flange connected with the equipment. Integral flange is mostly used in equipment manufacturing and is hardly used in pipeline design.
Application
Carbon steel integral flange is mainly used in boiler and pressure vessel, petroleum, chemical industry, shipbuilding, pharmacy, metallurgy, machinery, stamping elbow, food and other industries.
