NeFeB Standard Permanent Magnetic Lifter 1 Ton To 30 Ton
Standard Permanent Magnetic Lifter
Why Choose Us?
Safety, Magnetism Continue 30years Without Electric. Energy saving, Above 95%.
The Clamping Force Can Be As nigh As More Than 20 Kg/cm2.
High Efficiency, Improve The efficiency of More Than 60%.
Very Easy to Use, Fast, Durable, Maintenance Free.
Specification sheet
| Model | Rated lifting capacity (Kgf) | Cylindrical lifting force (Kgf) | Dimension (mm) | Max pull-off force (Kgf) | Net Weight(kg) | |||
| A(length) | B(width) | C(height) | D(Handle length) | |||||
| PML-100 | 100 | 30 | 92 | 65 | 69 | 155 | 350 | 2.5 |
| PML-200 | 300 | 100 | 130 | 88 | 69 | 155 | 900 | 5.5 |
| PML-400 | 400 | 120 | 165 | 95 | 95 | 200 | 1200 | 10 |
| PML-600 | 600 | 200 | 210 | 115 | 116 | 230 | 1800 | 19 |
| PML-1000 | 1000 | 300 | 260 | 135 | 140 | 255 | 3000 | 35 |
| PML-1500 | 1500 | 500 | 340 | 135 | 140 | 255 | 4500 | 45 |
| PML-2000 | 2000 | 600 | 356 | 160 | 166 | 320 | 6000 | 65 |
| PML-3000 | 3000 | 1000 | 444 | 160 | 166 | 380 | 9000 | 85 |
| PML-4000 | 4000 | 1300 | 520 | 175 | 175 | 550 | 12000 | 150 |
| PML-5000 | 5000 | 1500 | 620 | 220 | 220 | 600 | 15000 | 210 |
| PML-6000 | 6000 | 2000 | 650 | 270 | 265 | 700 | 18000 | 300 |
| PML-10000 | 10000 | 3000 | 800 | 235 | 290 | 800 | 30000 | 395 |
| Note: Other specifications can be customized ,please call for further information. | ||||||||
FAQ
Q: Are you manufactory or trade company.
A: We are both factory and trade company, we have lots of Cooperation factory with different quality and prices, just tell us your need, there is always a product suitable for you.
Q: Where do you located:
A: JYC technology Co.,Ltd. located at Wuxi City, Jiangsu Province, 1 hour by fast rail way to Shanghai City.
Q: Production time:
A: Normally,We'll have regular items in stock, customized products will take 7-14 work days.
Q: Payment term:
A: TT, credit card, L/C, Western Union, Paypal and so on, we accept all kinds of payment.
Q: What's your work time:
A: Normally, our work time is 9: 00 AM to 17: 00 PM Beijing time, but if you have emergency, Please contact us freely at any time. Our salesman will sulove your problem as soon as possible.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
