25m/Min Corrugated Sheet Forming Machine Aluminium Roofing Making

Steel & aluminium sheet Making Machinery Sheet Roll Forming Machine

This machine can customize the tile length according to the requirements ,there is the construction of the computer controller to set up multiple sets of different data,easy operate.
The equipment automatically set in accordance with the computer data to produce different lengths of finished products.

Station Formation: 11 Stations
Shaft Diameter: 50mm
Machine Stand: Column Type
Machine Frame: Welded Carbon Steel
Roller Material: Cr12
Shaft Material: 45 # Tempered And Tempered Steel
Work Speed: 15-25m / min
Bearing: Roller Bearing
Transmission: By Gear
Motor Power: 5.5kw

Article No.	Item Name	Specification
1	Width of feeding material	119mm coil sheet
2	Thickness of feeding material	0.8mm-1.2mm coil sheet
3	Roller station	12 stations
4	Shaft Diameter	50mm
5	Productivity	8-12m/min
6	Rollers' material	45# steel forge
7	Shaft material	45# steel
8	Weight	2 ton
9	length	5.5 m
10	Voltage	380V 50Hz 3phases
11	Control	PLC
12	Decoiler	1.5Tons
13	Motor	5.5KW
14	Driving way	Chain transmission
15	Chain size	1 inch
16	Cutting system	Hydraulic cutter

Work flow:
manual uncoiler-- roll forming machine-- PLC control box-- hydraulic system-- post cut-- output table
