30m/Min Light Gauge Steel Roll Forming Machine 5.5KW
Price:
Negotiation
MOQ:
1 Set
Delivery Time:
40-60 days
Brand:
HENGRUIYANG
Product Description
Light Gauge Steel Roll Forming Machine ceiling grid machine, light gauge steel framing machine
1. Specifications of light gauge steel framing machine
1) Main Techincal Data:
| Size | 3700*800*1000mm |
| Weight | 3T |
| Profile Size | 89*38*9mm |
| Main Servo Motor Power | 5.5KW |
| Hydraulic Motor Power | 5.5KW |
| Voltage | 380V/50HZ/3PH |
| Forming Steps | 9+2steps for reshaping |
| Processing Speed | 25-30m/min |
| Feeding Width | 174mm |
| Efficient Width | 89mm |
| Thickness | 0.7-1.2mm |
| Tolerence Of Forming | ±0.5mm |
| Color | Magic Green |
| Decoiler | 5tons Decoiler |
2) Main Accessories:
(1) Main Forming Machine;
(2) Hydraulic Strip Uncoiler;
(3) Hydraulic Punching Device;
(4) Hydraulic Motor System;
(5) PLC Computer Controlling System With Touch Screen;
(6) Hydraulic Forming Cutter;
(7) Automatic Printing Device;
(8) Design Software;
(9) Run Out Table;
(10) Tools;
(11) Operation Manual.
