40km 10G SFP+ AOC DAC Cable DWDM Fiber Optical Transceiver LC Duplex DOM C17-C61
10G SFP+ 40km DWDM Fiber Optical Transceiver LC duplex DOM C17~C61
Description of Optical Module
DWDM SFP+ transceivers are designed to transmit and receive optical data over single mode optical fiber. Digital diagnostic functions are available via an I2C.This module is designed for single mode fiber and operates at a nominal wavelength of ITU Grid,C Band DWDM wavelength. It is with the SFP+ 20-pin connector to allow hot plug capability. The transmitter section uses a DWDM EML laser and is a class 1 laser compliant according to International Safety Standard IEC-60825.The receiver section uses a PIN detector and a limiting post-amplifier IC.
Specification of Optical Module
|
Data Rate |
distance | wavelength | LD | PD | Connector | DDM |
| 10G | 40km | CWDM(1270-1330nm) | DFB | PIN | LC | Y |
| 10G | 80km | CWDM(1470-1610nm) | EML | APD | LC | Y |
Features of Optical Module
Optical interface compliant to IEEE 802.3ae
Electrical interface compliant to SFF-8431
Specifications compliant with SFF 8472
Hot Pluggable
Low power consumption
All-metal housing for superior EMI performance
Single +3.3v power supply
Support Digital Diagnostic Monitoring Interface
Case operating temperature range: 0°C to 70°C
RoHS 6 compliant and lead free
Satisfy Class I safty requrement
Application of Optical Module
10G Ethernet with FEC
10Gbps SONET/SDH ITU-T G.959.1 P1L1-2D2
10Gbps SONET/SDH ITU-T G.709
10G BASE-ZR/ZW
SFP footprint 80km 10G Fiber Channel
