20L Rotary evaporator for binder recovery Asphalt bituminous mixture

Price Negotiable
Price: Negotiation
MOQ: 1 set
Delivery Time: Negotiable
Brand: TOPTION
Product Description

20L Rotary evaporator for binder recovery Asphalt bituminous mixture

20L Rotary evaporator for binder recovery Asphalt bituminous mixture ISO & CE certified manufacturer, RE-5220ADex rota evaporator is equipped with explosion proof system of motor, controller and bath. Is an idea instrument for concentration, drying and recycling.

Parameters for 20L Rotary evaporator for binder recovery Asphalt bituminous mixture
Model:
RE-5220A
Rotation flask:
20L
Receiving flask
10L
Lifting type
Automatic lifting
Condenser
vertical type, double serpentine tube
Rotation speed
5-110 rpm
Evaporation speed (H2O):
5L/h
Bath power:
5KW
Staic temp control range & Wave
RT~99℃ & 2℃
Standard power:
220V 50/60Hz single phase
Motor power
120W
Dimension
1100 x 700 x 2000mm
Dispaly
Rotation speed and temperature are digital display
Optional
oil hath; 110V 60Hz single phase working voltage
Related Products
Name & Model
Parameters
Chiller LX-0400
1. Model: LX-0400
2. Working temperature range: -25~30℃
3. Pump max.Vpc:20L/min; 0.7bar
4.Power supply: 220V 50/60Hz
5. Cooling power (kw) at (℃): 0℃-2.4Kw,
                                                              -10℃-1.5Kw,
                                                              -20℃-0.8Kw
6. Compressor: France Taikang
7. Tank volume: 25L
8. Connection port: DN20
9. Temp control system: ASET multi-functional controller
10. Size: 550*500*850mm
11. Standard Power: 220V 50/60Hz
Vacuum Pump SHB-B95
1. Largest vacuum: 0.098Mpa
2. Single-head exhaust volume: 10L/min
3. Exhaust the number of heads: 5
4. Tank capacity: 57L
5. Circulation flow rate: 100L/min
6. Pump head: 12m
7. Standard Power: 220V 370W
8.Dimension:450*350*950mm
9.Weight: 40kg
