2 Ton Sit Down Electric Forklift With Curtis Accelerator

Price Negotiable

Price: Negotiable

MOQ: 1

Delivery Time: 8 work days

Brand: JAC FORKLIFT

Product Description

Electric Forklift (2.0T Four Wheel Forklift, S Series)

Product description

The electric forklift of H series employs asymmetric drive axle, to leave enough space for the installation of the travel motor. So, the motor replacement and maintenance can be completed easily, without troublesome dismantling of the gear box and drive axle. This design has been granted the national patent.

Features

1. The steering axle of the 1-1.8T four wheel forklift offers big turning angle to reduce the turning radius and enhance the trafficability of the electric forklift. The patented technology makes this product quite popular.

2.Iron cover for the balance weight of the electric forklift has high strength and good resistance to crush.

3. Thanks to the LCD instrument panel with good resistance to water and vibration from CURTIS, the important information can be displayed on the screen completely, enabling the user to understand the working conditions of the material handling equipment timely and precisely.

4. This range of product is installed with CURTIS accelerator. According to ergonomics, the foot brake pedal is designed slightly higher than the accelerator.

5.Imported AMP connector to ensure high reliability of the electrical circuit.

Technical Parameters of Diesel Forklift

Model	Unit	CPD20S	CPD25S
Powe type		Battery
Rated load	kg	2000	2500
Load center distance	mm	500
Lift height	mm	3000
Fork size	mm	1070×120×40
Minimum turning radius	mm	2060
Maximum travel speed/Full load	km/h	13
Maximum travel speed/No load		14
Fork height at maximum lift (with backrest)	mm	4280
Standard Mast height	mm	1985
Front wheel		23×9-10-18PR
Rear wheel		18×7-8-14PR
Tread Front wheel/rear wheel	mm	960/960
Self weight Without load	kg	3700	4100
Battery Voltage/capacity	V/Ah	48V/404 lithium battery	48V/404 lithium battery
Motor/Traveling	KW	11
