Private Mobile Radio FM DAB Antenna Covert Vehicle Dipole

Price Negotiable

Price: USD$ 1.2 / PCS - USD$ 1.5 / PCS

MOQ: 10 PCS

Delivery Time: 5-8 days

Brand: MS

Product Description

1. Product Name

Private Mobile Radio Covert Vehicle Dipole FM/DAB Antenna

2. Introduction

FM: 88-108MHz

DAB: 174-240MHz

Dipole Antenna

Tunable to Individual User

Flexible Wire Elements

This covert vehicle dipole antenna is specifically designed for installations where the presence of an antenna must be undertectable.

This specialist antenna can be tuned across a range of frequencies from FM to DAB (L1) when fitted simply by cutting down the radiating elements. Tuning on the vehicle ensures that a good VSWR match can be achieved in the installed location [with a bandwidth of approximately 8% of centre frequency.]

3. Antenna Specifications

Electrical Properties

1.1	Frequency	88-108 MHz / 174-240 MHz
1.2	Gain (peak)	2 dBi
1.3	V.S.W.R	2.5 MAX
1.4	Return Loss	-10dB Maximum
1.5	Radiation	Omni-Directional
1.6	Polarization	Linear / Vertical
1.7	Power Handling	2 W

Mechanical Properties

2.1	Cable	7*16 Pure Brass Cable
2.2	Antenna Cover	PE
2.3	Antenna Base
2.4	Operating Temperature	-20℃ ~ +65℃
2.5	Storage Temperature	-30℃ ~ +75℃
2.6	Color	Black
2.7	Connector	F Male
