12v 150Ah LiFePO4 Deep Cycle Battery For RV Caravan Camping
Deep cycle battery for RV caravan camping 12v 150Ah battery with heating and bluetooth
LiFePO4 is the more efficient technology batteries, knocking out traditional lead acid batteries . VODNO provides a complete line of 12, 24 and 48 volt batteries for use in RV’s, Boats, EV's and off-grid applications and much more.
Overview
The LiFeP04 Battery (also known as Lithium Iron Phosphate) is a reliable, high performance, cost effective solution to an AGM/Lead Acid Battery. The LiFeP04 batteries are the safest type of Lithium chemistry on the market today. Due to the cathode material inside of each cell, the batteries will not overheat or catch fire (even if punctured). There are also no health or environmental hazards. The LiFeP04 battery is so stable it will accept a charge from most standard chargers designed for lead-acid batteries.
With the advanced BMS (Battery Management System) and the advantages over conventional Lead Acid batteries the LiFeP04 Batteries are the clear choice.
Specifications
| Model | VDO-LF12150 | |||
| General Characteristics | ||||
| Nominal voltage | 12.8V | |||
| Nominal capacity@0.2C | 150Ah | |||
| Nominal energy | 1920Wh | |||
| Internal Resistance | 35≦mΩ | |||
| Life cycle | >2000Cycles @0.2C Charging /Discharging at 90%DOD | |||
| Self-Discharge | ≤3.5%per month at 25℃ | |||
| Standard Charging | ||||
| Charging voltage | 14.6+/-0.2V | |||
| Charging Mode(CC/CV) | At 0℃~45℃temperature, charged to 14.6V at constant current 0.2C5A,and then at constant voltage 14.6V until the current drops to 0.02C5A | |||
| Charging Current | 40A | |||
| Max.Charging Current | 150A | |||
| Standard Discharging | ||||
| Discharging Current | 40A | |||
| Max.Continuous Current | 150A | |||
| Max.Pulse Current | 300A(<3S) | |||
| Discharging cut-off Voltage | 10.0V | |||
| Operating conditions | ||||
| Operating temperature | Charge | 0℃～45℃ | ||
| Discharge | －20℃～60℃ | |||
| Storage temperature | 0℃～45℃ | |||
| Water dust resistance | IP56 | |||
| Structure | ||||
| Casing | ABS | |||
| Dimension | 330*172*215mm | |||
| Approx.Weight | 16.5kgs | |||
| Terminal | M8 | |||
Application
Lithium’s lifepo4 Batteries include Bluetooth Battery Monitoring with the bluetooth App, heating function. Upgraded Cells and a more smart BMS. Available in a 120Ah Starting Battery, 100Ah and 60Ah batteries. 12v batteries are capable of series and parallel connections!
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
