Stackable LiFePO4 Battery 10kWh 15KWh 20KWh Lithium Iron Phosphate Rechargeable Pack
Price:
$2,073.00/pieces 2-10 pieces
MOQ:
2 pieces
Delivery Time:
Negotiable
Product Description
Stackable LiFePO4 Battery 10kWh 15KWh 20KWh Lithium Iron Phosphate Rechargeable Pack Solar Energy Storage System
Products Description
The most complete household energy storage battery system
A battery energy storage system is an electrochemical device that charges or collects energy from the grid or a power plant and then discharges that energy at a later time to provide electricity or other grid services when needed. Battery storage is an important technology that can enhance power system flexibility and enable high levels of renewable energy integration. Modern battery energy storage systems usually include a built-in inverter and computerized control systems that make them simple to install, largely maintenance-free and do not require any effort or expertise from the user. Battery energy storage systems have a wide range of applications for both commercial and residential purposes. Commercial applications include peak shaving, load shifting, emergency backup, and various grid services. Residential applications include self-consumption, off-grid homes and emergency backup.
A battery energy storage system is an electrochemical device that charges or collects energy from the grid or a power plant and then discharges that energy at a later time to provide electricity or other grid services when needed. Battery storage is an important technology that can enhance power system flexibility and enable high levels of renewable energy integration. Modern battery energy storage systems usually include a built-in inverter and computerized control systems that make them simple to install, largely maintenance-free and do not require any effort or expertise from the user. Battery energy storage systems have a wide range of applications for both commercial and residential purposes. Commercial applications include peak shaving, load shifting, emergency backup, and various grid services. Residential applications include self-consumption, off-grid homes and emergency backup.
Product Paramenters
|
Model
|
VDO-5kwh
|
VDO-10kwh
|
VDO-20kwh
|
VDO-30kwh
|
|
Dimension(W*D*H)
|
570*400*390
|
570*400*550
|
570*400*870
|
570*400*1190
|
|
Weight
|
70kg
|
120kg
|
220kg
|
320kg
|
Battery Specifications
|
Rated voltage
|
51.2V
|
|
|
|
|||
|
Rated Capacity
|
5kwh
|
10kwh
|
20kwh
|
30kwh
|
|||
|
Configuration
|
1* 100Ah
|
2* 100Ah
|
3* 100Ah
|
4* 100Ah
|
|||
|
Discharge/charge Current
|
0.5C
|
|
|
|
|||
|
Cooling Method
|
Self-Cooling
|
|
|
|
|||
|
Battery Type
|
Lithium Iron Phosphate 3.2v 105Ah
|
|
|
|
|||
|
Use Period
|
>15 Years@25°C
|
|
|
|
|||
|
Cycle Life
|
6000 times
|
|
|
|
|||
|
Communication
|
RS485/CAN/RS232
|
|
|
|
|||
|
Certification
|
UL1973,UL9540,CE,UN38.3,MSDS
|
|
|
|
|||
Inverter Specifications
|
Rated Grid Frequency
|
50HZ/60HZ Auto Detect
|
|
|
|
|||
|
AC input Range
|
110V/220V(90Vac-240Vac)±2%
|
|
|
|
|||
|
Rated output voltage
|
120Vac(100/105/110Vac)
|
|
|
|
|||
|
Rated output power
|
5000W(Peak10000W)
|
|
|
|
|||
|
The charging and discharging efficiency
|
>95%
|
|
|
|
|||
|
Battery Voltage Range
|
48V (min starting voltage 44V)
|
|
|
|
|||
|
Max overload current
|
63A
|
|
|
|
|||
AC Charging mode
|
Max charging current
|
40A
|
|
|
|
|||
|
Charge voltage range
|
40-60Vdc
|
|
|
|
|||
|
Short circuit breaker spec
|
63A
|
|
|
|
|||
Solar Charging mode
|
Max PV open circuit voltage
|
500Vdc
|
|
|
|
|||
|
PV operating voltage
|
120-500Vdc
|
|
|
|
|||
|
MPPT voltage range
|
120-450Vdc
|
|
|
|
|||
|
Max output power
|
5000w
|
|
|
|
|||
|
Solar Charging current
|
0-80A
|
|
|
|
|||
AC Output
|
Output voltage waveform
|
Pure sine wave
|
|
|
|
|||
|
Rated output voltage
|
5000(4100/4300/4500)
|
|
|
|
|||
|
Rated output power
|
5000(4100/4300/4500)
|
|
|
|
|||
Enviroment Condition
|
Working tempreture range
|
0°C-55°C
|
|
|
|
|||
|
Humidity range
|
5%-95%
|
|
|
|
|||
|
Nolse emission
|
≤60dB
|
|
|
|
|||
Our Advantages
* Stacking Design - Modular stack design, flexible power use
* BMS system- Built in BMS system ensure battery safety
* Pulley design- battery chassis with pulleys
* Easy to install- easy installation, plug and play, fuse protection
* Low voltage 5Kwh-50kwh energy storage system
* BMS system- Built in BMS system ensure battery safety
* Pulley design- battery chassis with pulleys
* Easy to install- easy installation, plug and play, fuse protection
* Low voltage 5Kwh-50kwh energy storage system
* All in one system including inverter
Why Choose Us
1. Strong adaptability and is compatible with more than ten brands of inverters, such as Pylontech, Growatt, Sermatec,
FoxESS,Victron energy,Voltronk Power, Sofar, SMA, TBB, Deye, Luxpower and so on.
2. Low voltage and high voltage are option, Low voltage means it is consisted of 15 pcs of LFP cell,The Operating voltage range 42V~54V, High voltage means the Operating voltage range 102V~512V. LFP cell voltage is 3.2V from China famous brands,Such as CATL,BYD,CALB and so on.
3. Safety certification: Cell: CE,UL,IEC 62109-1&-2, IEC 62477,EN61000,UN38.3
Battery pack: CE, UN38.3, MSDS, Shipping, Dangerous Package
Hazardous Material Classification: CLass 9
Transportation: UN38.3
Ingress Rating: IP55
4. Warranty: The battery retains at least 80% of Nominal Energy for 7 years after the date of invoice and at least 60% of Nominal Energy for 10 years after under proper conditions of the use during the Term of Performance Warranty
FoxESS,Victron energy,Voltronk Power, Sofar, SMA, TBB, Deye, Luxpower and so on.
2. Low voltage and high voltage are option, Low voltage means it is consisted of 15 pcs of LFP cell,The Operating voltage range 42V~54V, High voltage means the Operating voltage range 102V~512V. LFP cell voltage is 3.2V from China famous brands,Such as CATL,BYD,CALB and so on.
3. Safety certification: Cell: CE,UL,IEC 62109-1&-2, IEC 62477,EN61000,UN38.3
Battery pack: CE, UN38.3, MSDS, Shipping, Dangerous Package
Hazardous Material Classification: CLass 9
Transportation: UN38.3
Ingress Rating: IP55
4. Warranty: The battery retains at least 80% of Nominal Energy for 7 years after the date of invoice and at least 60% of Nominal Energy for 10 years after under proper conditions of the use during the Term of Performance Warranty
Details Images
FAQ
Q1.: Are you a manufacture or a trading company ?
A1.: Yes. we are both.
Q2.: Can I get some samples?
A2.: Yes, sample order is available for quality check and market test. After we received charges of sample, the sample will be delivered in 7-15 days.
Q3.: Can you do the design for us?
A3.: Yes. We have a professional designing team which is provide OEM and ODM. Just tell us your ideas and we can help to carry out your ideas. Send us HD images, your logo and text, we would like to arrange them according to your requirements. The final files need to confirmed by you.
Q4.: Does inverter built in battery pack system?
A4.: Yes, we have both for with and without inverter for your choice. if you have a inverter already, just let us know details of communication protocol, we can help check if our battery system is support, or adjust our battery system to support them.
Q5.: How about the delivery time?
A5: It depends on the quantity and the season you place an order. Usually takes about 5-7 working days for 10 units production.
Q6.: What is your terms of delivery shipping?
A5: It depends on the quantity and the season you place an order. Usually takes about 5-7 working days for 10 units production.
Q7.: What is your warranty?
A6.: We accept EXW, FOB, CFR, CIF, DDP, DDU,etc. We could give you best suggestion of shipping way based on destination.
Q8.: Do you sell inverter or solar panel also?
A8.:We are professional storage battery system manufacturer, we only produce battery, but if you need help, Pls talk to sales staff about your requirements, we will help to provide with it.
Application
