Load Cell Gel Silicone Electrical Insulation Silicone Gel 1:1 10 Shore A Transparent Silicone Thermal Gel
Load Cell Gel Silicone Electrical Insulation Silicone Gel 1:1 10 Shore A Transparent Silicone Thermal Gel
Product Description of softness silicone gel:
Silicone gel is a polymeric material derived from a polysiloxane structure. It's typically supplied as a two-part (A/B) liquid system that, when mixed, cures at room temperature or under heat to form a soft, elastic gel. Its hardness is significantly lower than standard silicone rubber, and it has a jelly-like texture. It's characterized by exceptional flexibility and resilience, effectively absorbing external impact forces while maintaining stable performance over extended periods.
Product Features of softness silicone gel:
1. Low viscosity, bubble-free
2. Appearance: clear liquid
3. Temperature Resistance: -60-200℃
4. Waterproof
5. Strong vibration resistance, low stress, and high impact resistance
6. Yellowing-resistant and UV-resistant
7. Highly flexible; becomes soft as jelly after curing etc
Product application of softness silicone gel:
1. New Energy Vehicles: BMS and Battery Cell Protection
2. LED Packaging and Lighting Driver Power Supply
3. High-voltage power supply and communication module
4. Medical and Wearable Devices
5. Industrial and Military Controllers
Physical Properties of softness silicone gel
|
Characteristics before curing
|
||
|
Component
|
Component A
|
Component B
|
|
Color
|
Transparent liquid
|
Transparent liquid
|
|
viscosity(cp s. 25℃)
|
800～2000
|
800～1800
|
|
Relative density(mpa•s)
|
1 ．0～1.12
|
0.98～1.02
|
|
The mixing ratio
|
A:B=1:1
|
|
|
Viscosity after mixing(cp s. 25℃)
|
800～1500
|
|
|
Operate Time (25℃)
|
2 h
|
|
|
Penetration (1/10mm)
|
200~ 400
|
|
|
Curing conditions (120℃)
|
20~30 mins
|
|
|
Cured properties
Hardness(Shore A, 24hr)
|
0～10
|
|
